422

BRZ_U

5-2. Steps to take in an emergency

If a warning light turns on or a warning buzzer sounds...

Stop the vehicle immediately. Continuing to drive the vehicle
may be dangerous.

The following warning indicates a possible problem in the brake sys-
tem. Immediately stop the vehicle in a safe place and contact your
SUBARU dealer.

Warning light

Warning light/Details

 (U.S.A.)

 (Canada and

Mexico)

Brake system warning light
• Low brake fluid
• Malfunction in the brake system

This light also comes on when the parking brake is not
released. If the light turns off after the parking brake is fully
released the system is operating normally.

Calmly perform the following actions if any of the warning lights turn
on or flash. If a light turns on or flashes, but then turns off, this does
not necessarily indicate a malfunction in the system.

5

Whe

n tro

ubl
e a
ris

es

423

5-2. Steps to take in an emergency

BRZ_U

Stop the vehicle immediately.

The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your SUBARU dealer.

Warning light

Warning light/Details

Charging system warning light

Indicates a malfunction in the vehicle’s charging system.

Low engine oil pressure warning light

Indicates that the engine oil pressure is too low.

(Flashes or illu-

minates in red)

High engine coolant temperature warning light (if
equipped)

Indicates that the engine is almost overheating. (

→P. 479)

As the engine coolant temperature increases, this warning
light will change from flashing to constantly illuminated.

424

5-2. Steps to take in an emergency

BRZ_U

Have the vehicle inspected immediately.

Failing to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your SUBARU dealer immediately.

Warning light

Warning light/Details

 (U.S.A.)

 (Canada and

Mexico)

Malfunction indicator lamp

Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system;
• The electronic automatic transmission control system.

SRS airbag system warning light

Indicates a malfunction in:
• The SRS airbag system;
• The seatbelt pretensioner system;
• The front passenger occupant detection system.

 (U.S.A.)

 (Canada and

Mexico)

ABS warning light

Indicates a malfunction in:
• The ABS;
• The brake assist system.

Electric power steering warning light (warning buzzer)

Indicates a malfunction in the electric power steering sys-
tem.

Slip indicator

Indicates a malfunction in:
• The Vehicle stability control (VSC) system;
• The TRAC system;
• The hill start assist system.

Automatic headlight leveling system warning light

Indicates a malfunction in the automatic headlight leveling
system.

5

Whe

n tro

ubl
e a
ris

es

425

5-2. Steps to take in an emergency

BRZ_U

(Comes on in

yellow)

Cruise control indicator light

Indicates a malfunction in the cruise control system.

■

If the malfunction indicator lamp comes on while driving

First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The malfunction indicator lamp will go off after several driving trips.
If the malfunction indicator lamp does not go off even after several trips, con-
tact your SUBARU dealer as soon as possible.

■

SRS airbag system warning light
→P. 129

■

Electric power steering warning light (warning buzzer)

The electric power steering warning light may come on and the warning
buzzer may sound when the voltage is low or the voltage drops.

WARNING

■

When the electric power steering warning light comes on

The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold
firmly and operate using more force than usual.

Warning light

Warning light/Details

426

5-2. Steps to take in an emergency

BRZ_U

Follow the correction procedures.

After taking the specified steps to correct the suspected problem,
check that the warning light turns off.

Warning light

Warning light/Details

Correction procedure

Open door warning light (if
equipped)

Indicates that a door or the
trunk lid is not fully closed.

Check that both side doors
and the trunk lid are closed.

(Comes on in

yellow)

Low fuel level warning
light

Remaining fuel
(Approximately 1.8 gal.
[7.0 L, 1.5 Imp. gal.] or
less)

Refuel the vehicle.

(On the instru-

ment cluster)

Driver’s seatbelt
reminder light
(warning buzzer)

*1

Warns the driver to fasten
his/her seatbelt.

Fasten the seatbelt.

(On the center

panel)

Front passenger’s seatbelt
reminder light
(warning buzzer)

*2

Warns the front passenger
to fasten his or her seatbelt.

Fasten the seatbelt.

5

Whe

n tro

ubl
e a
ris

es

427

5-2. Steps to take in an emergency

BRZ_U

Tire pressure warning
light (if equipped)

When the light comes on:
Low tire inflation pressure
such as
• Natural causes (

→P. 429)

• Flat tire (

→P. 451)

Adjust the tire inflation
pressure to the specified
level.

The light will turn off after
a few minutes. In case the
light does not turn off
even if the tire inflation
pressure is adjusted,
have the system checked
by your SUBARU dealer.

When the light comes on
after blinking for approxi-
mately one minute:
Malfunction in the tire pres-
sure monitoring system
(

→P. 430)

Have the system checked
by your SUBARU dealer.

Automatic transmission
fluid temperature warning
light (if equipped)

Indicates that the auto-
matic transmission fluid
temperature is too high.

Stop the vehicle in a safe
place and shift the select
lever to P.
If the light goes off after a lit-
tle while, the vehicle can be
driven. If the light does not
go off, contact your
SUBARU dealer.

Master warning light (if
equipped)

A buzzer sounds and the
warning light comes on and
flashes to indicate that the
master warning system has
detected a malfunction.

→P. 434

Warning light

Warning light/Details

Correction procedure

428

5-2. Steps to take in an emergency

BRZ_U

*1

: Driver’s seatbelt buzzer:

Vehicles without a keyless access with push button start system

The driver’s seatbelt buzzer sounds to alert the driver that his or her seatbelt
is not fastened. Once the engine switch is turned to the “ON” position, the
buzzer sounds for 6 seconds. If the vehicle reaches a speed of 12 mph (20
km/h), the buzzer sounds once. If the seatbelt is still unfastened after 24
seconds, the buzzer will sound intermittently for 10 seconds. Then, if the
seatbelt is still unfastened, the buzzer will sound in a different tone for 20
more seconds.

Vehicles with a keyless access with push button start system

The driver’s seatbelt buzzer sounds to alert the driver that his or her seatbelt
is not fastened. Once the

push-button ignition switch is turned to “ON”

mode, the buzzer sounds for 6 seconds. If the vehicle reaches a speed of
12 mph (20 km/h), the buzzer sounds once. If the seatbelt is still unfastened
after 24 seconds, the buzzer will sound intermittently for 10 seconds. Then,
if the seatbelt is still unfastened, the buzzer will sound in a different tone for
20 more seconds.

*2

: Front passenger’s seatbelt buzzer:

The front passenger’s seatbelt buzzer sounds to alert the front passenger
that his or her seatbelt is not fastened. The buzzer sounds once if the vehi-
cle reaches a speed of 12 mph (20 km/h). If the seatbelt is still unfastened
after 24 seconds, the buzzer will sound intermittently for 10 seconds. Then,
if the seatbelt is still unfastened, the buzzer will sound in a different tone for
20 more seconds.

5

Whe

n tro

ubl
e a
ris

es

429

5-2. Steps to take in an emergency

BRZ_U

■

Low fuel level warning light

When the vehicle is on an incline, curve and so forth, the fuel inside the tank
moves, which may cause the warning light to come on early.

■

Front passenger detection sensor and passenger seatbelt reminder
and warning buzzer

●

If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash and warning
buzzer to sound, even if a passenger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.

■

When the tire pressure warning light comes on (if equipped)
Check the tire inflation pressure and adjust to the appropriate level.

■

The tire pressure warning light may turn on due to natural causes
(if equipped)
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflation pressure changes caused by temper-
ature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after a few minutes).

■

When a tire is replaced with a spare tire (vehicles with a tire pres-
sure monitoring system)
The compact spare tire is not equipped with a tire pressure warning
valve and transmitter. If a tire goes flat, the tire pressure warning light will
not turn off even though the flat tire has been replaced with the spare
tire. Replace the spare tire with the repaired tire and adjust the tire infla-
tion pressure. The tire pressure warning light will go off after a few min-
utes.

430

5-2. Steps to take in an emergency

BRZ_U

■

If the tire pressure monitoring system is inoperative (if equipped)
The tire pressure monitoring system will be disabled in the following con-
ditions:
(When the condition becomes normal, the system will work properly.)

●

If tires not equipped with tire pressure warning valves and transmit-
ters are used.

●

If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer.

●

If the tire inflation pressure is 55 psi (380 kPa, 3.80 kgf/cm

2

 or bar) or

higher.

The tire pressure monitoring system may be disabled in the following
conditions:
(When the condition becomes normal, the system will work properly.)

●

If electronic devices or facilities using similar radio wave frequencies
are nearby.

●

If a radio set at similar frequencies is in use in the vehicle.

●

If a window tint that affects the radio wave signals is installed.

●

If there is a lot of snow or ice on the vehicle, in particular around the
wheels or wheel housings.

●

If non-genuine SUBARU wheels are used. (Even if you use SUBARU
wheels, the tire pressure monitoring system may not work properly
with some types of tires.)

●

If tire chains are used.

●

If a large metallic object which can interfere with signal reception is
put in the trunk.

■

If the tire pressure warning light frequently comes on after blinking
for approximately one minute (if equipped)
If the tire pressure warning light frequently comes on after blinking for
approximately one minute when the push-button ignition switch is turned
to “ON” mode (vehicles with a keyless access with push button start sys-
tem) or the engine switch is turned to the “ON” position (vehicles without
a keyless access with push button start system), have it checked your
SUBARU dealer.

5

Whe

n tro

ubl
e a
ris

es

431

5-2. Steps to take in an emergency

BRZ_U

WARNING

■

If the tire pressure warning light comes on (if equipped)
Be sure to observe the following precautions. Failure to do so could
cause loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pres-
sure adjustment, it is probable that you have a flat tire. Check the tires.
If the tire is flat, change to the spare tire and have the flat tire repaired
by the nearest SUBARU dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur (vehicles with a tire
pressure monitoring system)
The tire pressure monitoring system may not activate immediately.

432

5-2. Steps to take in an emergency

BRZ_U

WARNING

■

Maintenance of the tires (vehicles with a tire pressure monitoring
system)
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation pressure
label (tire and load information label). (If your vehicle has tires of a differ-
ent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should determine the
proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS) that illuminates a low tire pressure
telltale (tire pressure warning light) when one or more of your tires is sig-
nificantly under-inflated. Accordingly, when the low tire pressure telltale
(tire pressure warning light) illuminates, you should stop and check your
tires as soon as possible, and inflate them to the proper pressure. Driv-
ing on a significantly under-inflated tire causes the tire to overheat and
can lead to tire failure. Under-inflation also reduces fuel efficiency and
tire tread life, and may affect the vehicle's handling and stopping ability.
Please note that the TPMS is not a substitute for proper tire mainte-
nance, and it is the driver's responsibility to maintain correct tire pres-
sure, even if under-inflation has not reached the level to trigger
illumination of the TPMS low tire pressure telltale (tire pressure warning
light).
Your vehicle has also been equipped with a TPMS malfunction indicator
to indicate when the system is not operating properly. The TPMS mal-
function indicator is combined with the low tire pressure telltale (tire pres-
sure warning light). When the system detects a malfunction, the telltale
will flash for approximately one minute and then remain continuously illu-
minated. This sequence will continue upon subsequent vehicle start-ups
as long as the malfunction exists. When the malfunction indicator is illu-
minated, the system may not be able to detect or signal low tire pressure
as intended.

5

Whe

n tro

ubl
e a
ris

es

433

5-2. Steps to take in an emergency

BRZ_U

WARNING

TPMS malfunctions may occur for a variety of reasons, including the
installation of replacement or alternate tires or wheels on the vehicle that
prevent the TPMS from functioning properly. Always check the TPMS
malfunction telltale after replacing one or more tires or wheels on your
vehicle to ensure that the replacement or alternate tires and wheels
allow the TPMS to continue to function properly.

CAUTION

■

To ensure the tire pressure monitoring system operates properly
(vehicles with a tire pressure monitoring system)
Do not install tires with different specifications or makers, as the tire
pressure monitoring system may not operate properly.

434

5-2. Steps to take in an emergency

BRZ_U

If a warning message is displayed (vehicles with a color multi-information display)

Stop the vehicle immediately. Continuing to drive the vehicle
may be dangerous.

The following warning indicates a possible problem in the brake sys-
tem. Immediately stop the vehicle in a safe place and contact your
SUBARU dealer.

Warning message

Details

(U.S.A.)

(Canada and Mexico)

Indicates that:
• The brake fluid level is low; or
• The brake system is malfunctioning

A buzzer also sounds.

If a warning is shown on the multi-information display, stay calm and
perform the following actions:

Master warning light

The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.

Multi-information display

If any of the warning light comes on again after the following
actions have been performed, contact your SUBARU dealer.

5

Whe

n tro

ubl
e a
ris

es

435

5-2. Steps to take in an emergency

BRZ_U

Stop the vehicle immediately.

The following warning indicates the possibility of damage to the vehi-
cle that may lead to an accident. Immediately stop the vehicle in a
safe place and contact your SUBARU dealer.

Warning message

Details

(Comes on in red)

Indicates that the engine is almost overheating.
(

→P. 479)

A buzzer also sounds.

436

5-2. Steps to take in an emergency

BRZ_U

Have the vehicle inspected immediately.

Failure to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your SUBARU dealer immediately.

Warning message

Details

Indicates a malfunction in:
• The SRS airbag system;
• The seatbelt pretensioner system;
• The front passenger occupant detection system.

A buzzer also sounds.

 (U.S.A.)

(Canada and Mexico)

Indicates a malfunction in:
• The ABS;
• The brake assist system.

A buzzer also sounds.

Indicates a malfunction in the electric power steer-
ing system.

A buzzer also sounds.

5

Whe

n tro

ubl
e a
ris

es

437

5-2. Steps to take in an emergency

BRZ_U

 (Flashes)

(Flashes in yellow)

Indicates a malfunction in the keyless access with
push button start system.

A buzzer also sounds.

Warning message

Details
