Subaru BRZ (2019 year). Manual - part 15

230

2-2. Instrument cluster

BRZ_U

Odometer/trip meter display area

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and display
different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

■

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to
122°F (50°C). Low outside temperature indicator comes on when the
ambient temperature is 37°F (3°C) or lower.

231

2-2. Instrument cluster

2

Wh
en driv

in

g

BRZ_U

■

G-force display

●

Depending on the vehicle usage conditions, the brake fluid pressure dis-
play may not reach its maximum reading even though the brake pedal is
fully depressed.

●

If a battery terminal is disconnected and reconnected, the steering
amount display may be disabled temporarily. After driving the vehicle for
a while, the display will be enabled.

■

Suspension of the settings display

●

The settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will
be suspended.

■

Using the stopwatch

If the engine is stopped while the stopwatch is operating, the stopwatch will
stop and the time up to that point will be recorded.

■

Outside temperature display

●

In the following situations, the correct outside temperature may not be
displayed.

• When the vehicle is very hot, such as when under the sun.
• When the vehicle is idling or being driven at low speeds such as in a

traffic jam or when the engine is stopped and then restarted immedi-
ately afterward.

• When the actual outside temperature is outside of the indicator range.

●

If “

− −” is displayed for approximately 1 minute or more or if the outside

temperature is not displayed, the system may be malfunctioning. Have
the vehicle inspected by your SUBARU dealer.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

232

2-2. Instrument cluster

BRZ_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious health
hazard.

CAUTION

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

233

2

Wh
en driv

in

g

BRZ_U

2-3. Operating the lights and windshield wipers

Headlight switch

The headlights can be operated manually or automatically.

Turning the end of the lever turns on the lights as follows:

Off

The daytime running lights
turn on. (

→P. 235)

The headlights, park-
ing/daytime running
lights

  (

→P. 235)

 and so

on turn on and off auto-
matically. (Vehicles
without a keyless
access with push but-
ton start system: When
the engine switch is in
the “ON” position
Vehicles with a keyless
access with push but-
ton start system: When
the push-button igni-
tion switch is in “ON”
mode)
The side marker, park-
ing, tail, license plate
and instrument panel
lights turn on.
The headlights and all
the lights listed above
(except daytime run-
ning lights) turn on.

234

2-3. Operating the lights and windshield wipers

BRZ_U

Turning on the high beam headlights

With the headlights on, push
the lever forward to turn on the
high beams.

The high beam indicator will illu-
minate when the high beams are
turned on.

Pull the lever back to the center
position to turn the high beams
off.

Pull the lever toward you and
release it to flash the high
beams once.

The high beam indicator will illu-
minate when the high beams are
flashed.

You can flash the high beams
with the headlights on or off.

235

2-3. Operating the lights and windshield wipers

2

Wh
en driv

in

g

BRZ_U

■

Daytime running light system

●

The daytime running lights illuminate using the same lights as the parking
lights and illuminate brighter than the parking lights.

●

To make your vehicle more visible to other drivers during daytime driving,
the daytime running lights turn on automatically when all of the following
conditions are met. (The daytime running lights are not designed for use
at night.)

• The engine is running
• The select lever is shifted out of P (Vehicles with an automatic trans-

mission)

• The parking brake is released
• The headlight switch is off or in the “AUTO”

*

 position

*: When the surroundings are bright

The daytime running lights remain on after they illuminate even if the parking
brake is set again.

●

When the turn signal indicators are flashing, the daytime running light on
the side that the turn signals are flashing will turn off.

●

When the hazard warning flashers are flashing, both daytime running
lights will turn off.

●

Compared to turning on the headlights, the daytime running light system
offers greater durability and consumes less electricity, so it can help
improve fuel economy.

■

Headlight control sensor

Headlight control sensor is located on the
passenger's side.

The sensor may not function properly if
an object is placed on the sensor, or any-
thing that blocks the sensor is affixed to
the windshield.

Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction.

236

2-3. Operating the lights and windshield wipers

BRZ_U

■

Welcome lighting system

When entering the vehicle
When the headlight switch is in

 and the doors are unlocked using the

remote keyless entry system, the headlights, front position lights, etc. will
illuminate for approximately 30 seconds.

The lights are turned off in the following situations.

●

The engine switch is turned to the “ON” position. (Vehicles without a key-
less access with push button start system)

●

The push-button ignition switch is turned to “ON” mode. (Vehicles with a
keyless access with push button start system)

●

The doors are locked.

When exiting the vehicle
Vehicles without a keyless access with push button start system:
The light switch is in

, the headlights and tail lights turn off 30 seconds

after a door is opened and closed if the key is removed from the engine
switch. (The lights turn off immediately if

 on the key is pressed after

all the doors are locked.)

To turn the lights on again, turn the engine switch to the “ON” position, or

turn the lights off and then back to

 or



.

Vehicles with a keyless access with push button start system:
The light switch is in

, the headlights and tail lights turn off 30 seconds

after a door is opened and closed if the push-button ignition switch is turned
off. (The lights turn off immediately if

 on the key is pressed or the

door lock sensor on the door handle is touched after all the doors are
locked.)

To turn the lights on again, turn the push-button ignition switch to “ON”

mode, or turn the light switch off and then back to

 or



.

■

Light reminder buzzer
Vehicles without a keyless access with push button start system
A buzzer sounds when the engine switch is turned to “LOCK” position and
the driver's door is opened with the key removed from the engine switch
while the lights are turned on.

Vehicles with a keyless access with push button start system
A buzzer sounds when the push-button ignition switch is turned off and the
driver's door is opened while the lights are turned on.

237

2-3. Operating the lights and windshield wipers

2

Wh
en driv

in

g

BRZ_U

■

Automatic headlight leveling system

The level of the headlights is automatically adjusted according to the number
of passengers and the loading condition of the vehicle to ensure that the
headlights do not interfere with other road users.

■

Windshield wiper-linked automatic headlights

When the headlight switch is in

, if the windshield wipers operate for

approximately 10 seconds, the headlights will turn on automatically. (If the
windshield wipers are operated due to operation of the windshield washers,
the headlights will not turn on automatically.) In this case, the headlights will
automatically turn off approximately 60 seconds after the windshield wipers
stop operating.

■

Battery-saving function

In the following conditions, the headlights and the other remaining lights will
go off automatically after 20 minutes in order to prevent the vehicle battery
from being discharged:

●

The headlights and/or tail lights are on.

●

The key is removed from the engine switch (vehicles without a keyless
access with push button start system) or the push-button ignition switch
is turned off (vehicles with a keyless access with push button start sys-
tem).

●

The light switch is in

,

 or

.

This function will be canceled in any of the following situations:

●

When the engine switch is turned to the “ON” position (vehicles without a
keyless access with push button start system) or the push-button ignition
switch is turned to “ON” mode (vehicles with a keyless access with push
button start system)

●

When the light switch is operated

●

When the door is opened or closed

■

Customization that can be configured at your SUBARU dealer

Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features

→P. 515)

238

2-3. Operating the lights and windshield wipers

BRZ_U

CAUTION

■

To prevent battery discharge

Do not leave the lights on longer than necessary when the engine is not run-
ning.

239

2-3. Operating the lights and windshield wipers

2

Wh
en driv

in

g

BRZ_U

Fog light switch

∗

■

Fog lights can be used when

The headlights are on in low beam.

The fog lights secure excellent visibility in difficult driving condi-
tions, such as in rain and fog.

Turns the front fog lights off
Turns the front fog lights on

∗

: If equipped

240

2-3. Operating the lights and windshield wipers

BRZ_U

Windshield wipers and washer

When intermittent windshield wiper operation is selected, the wiper
interval can be adjusted.

The wiper operation is selected by moving the lever as follows.

Intermittent windshield
wiper operation
Low speed windshield wiper
operation
High speed windshield
wiper operation
Temporary operation

Decreases the intermittent
windshield wiper frequency
Increases the intermittent
windshield wiper frequency

241

2-3. Operating the lights and windshield wipers

2

Wh
en driv

in

g

BRZ_U

■

The windshield wipers and washer can be operated when

Vehicles without a keyless access with push button start system
The engine switch is in the “ON” position.

Vehicles with a keyless access with push button start system
The push-button ignition switch is in “ON” mode.

■

If no windshield washer fluid sprays

Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid tank.

WARNING

■

Caution regarding the use of washer fluid

When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.

Washer/wiper dual opera-
tion

The wipers will automatically
operate a couple of times after
the washer squirts.

242

2-3. Operating the lights and windshield wipers

BRZ_U

CAUTION

■

When the windshield is dry

Do not use the wipers, as they may damage the windshield.

■

When the washer fluid tank is empty

Do not operate the switch continually as the washer fluid pump may over-
heat.

■

When a nozzle becomes blocked

In this case, contact your SUBARU dealer.
Do not try to clear it with a pin or other object. The nozzle will be damaged.

■

When adding washer fluid

Do not use strong cleaning agents as windshield washer fluid.

243

2

Wh
en driv

in

g

BRZ_U

2-4. Using other driving systems

Cruise control

Use the cruise control to maintain a set speed without depressing
the accelerator pedal.

Indicators
Cruise control switch

■

Setting the vehicle speed

Press the “ON-OFF” button to
activate the cruise control.

Cruise control indicator (green)
will come on.

Press the button again to
deactivate the cruise control.

Accelerate or decelerate the
vehicle to the desired speed,
and push the lever down to set
the speed.

“SET” indicator will come on.

The vehicle speed at the
moment the lever is released
becomes the set speed.

STEP

1

STEP

2

244

2-4. Using other driving systems

BRZ_U

■

Adjusting the set speed
To change the set speed, operate the lever until the desired set
speed is obtained.

Increases the speed
Decreases the speed

Fine adjustment: Momentarily
move the lever in the desired
direction.

Large adjustment: Hold the
lever in the desired direction.

The set speed will be increased or decreased as follows:

Fine adjustment (U.S.A.): By approximately 1 mph (1.6 km/h) each time
the lever is operated.

Fine adjustment (Canada and Mexico): By approximately 1 km/h (0.6
mph) each time the lever is operated.

Large adjustment: The vehicle speed can be increased or decreased
continually until the lever is released. Then, release the lever. The vehi-
cle speed at that moment will be memorized and treated as the new set
speed.

245

2-4. Using other driving systems

2

Wh
en driv

in

g

BRZ_U

■

Cruise control can be set when

Vehicles with an automatic transmission

●

The select lever is in D or M and the vehicle is in the 2

nd

 gear or higher.

●

Vehicle speed is above approximately 25 mph (40 km/h).

Vehicles with a manual transmission

●

The vehicle is in the 2

nd

 gear or higher.

●

Vehicle speed is above approximately 25 mph (40 km/h).

■

Canceling and resuming the constant speed control

Pulling the lever toward you
cancels the constant speed
control.

The speed setting is also can-
celed when:

• The brakes are applied.
• The clutch pedal is

depressed (manual trans-
mission only).

Pushing the lever up
resumes the constant
speed control.

Resuming is available when
the vehicle speed is more
than approximately 20 mph
(30 km/h).
