182

2-1. Driving procedures

BRZ_U

Engine (ignition) switch (vehicles without a keyless access with push button start system)

■

Starting the engine

Vehicles with an automatic transmission

Check that the parking brake is set.
Check that the select lever is set in P.
Firmly depress the brake pedal.
Turn the engine switch to the “START” position to start the
engine.

Vehicles with a manual transmission

Check that the parking brake is set.
Check that the shift lever is set in neutral.
Firmly depress the clutch pedal.
Turn the engine switch to the “START” position to start the
engine.

■

Changing the engine switch positions

“LOCK”

The steering wheel is locked
and the key can be removed.
(Vehicles with an automatic
transmission: The key can be
removed only when the select
lever is in P.)

“ACC”

Some electrical components
such as the power outlet can
be used.

“ON”

All electrical components can
be used.

“START”

For starting the engine.

STEP

1

STEP

2

STEP

3

STEP

4

STEP

1

STEP

2

STEP

3

STEP

4

183

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

■

Turning the key from “ACC” to “LOCK”

Vehicles with an automatic transmission: Shift the select lever to P.
(

→P. 185)

Vehicles with a manual transmission: Shift the shift lever to neutral.
(

→P. 192)

■

If the engine does not start

Remove the key and try again. If the engine does not start, the engine immo-
bilizer system may not have been deactivated. (

→P. 82)

Contact your SUBARU dealer.

■

When the steering lock cannot be released

■

Key reminder function

A buzzer sounds if the driver’s door is opened while the engine switch is in
the “LOCK” or “ACC” position to remind you to remove the key.

■

Immediately after reconnecting the battery terminals due to replacing
the battery and so forth

The engine may not start. If this occurs, turn the engine switch to the “ON”
position, and start the engine after waiting at least 10 seconds. Idling may be
unstable immediately after the engine starts, however, this is not a malfunc-
tion.

STEP

1

Push in the key and turn to the “LOCK”
position.

STEP

2

When starting the engine, the engine
switch may seem stuck in the “LOCK”
position. To free it, turn the key while turn-
ing the steering wheel slightly left and
right.

184

2-1. Driving procedures

BRZ_U

WARNING

■

When starting the engine

Always start the engine while sitting in the driver's seat. Do not depress the
accelerator pedal while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Caution when driving

Do not turn the engine switch to the “LOCK” position while driving. If, in an
emergency, you must turn the engine off while the vehicle is moving, turn the
engine switch only to the “ACC” position to stop the engine. An accident may
result if the engine is stopped while driving.

CAUTION

■

To prevent battery discharge

Do not leave the engine switch in the “ACC” or “ON” position for long periods
of time without the engine running.

■

When starting the engine

●

Do not crank the engine for more than 10 seconds at a time. This may
overheat the starter and wiring system.
If the engine does not start, turn the engine switch to the “LOCK” position
and try to start the engine again after waiting for 10 seconds or more.

●

Do not race a cold engine.

●

If the engine becomes difficult to start or stalls frequently, have your vehi-
cle checked by your SUBARU dealer immediately.

●

Vehicles with an automatic transmission: Do not shift the select lever while
the starter is operating.

185

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

Automatic transmission

∗

Select a shift position appropriate for the driving conditions.

■

Shifting the select lever

Vehicles without a keyless access with push button
start system
While the engine switch is in the “ON” position, move the
select lever with the brake pedal depressed.

When shifting the select lever between P and D, make sure that
the vehicle is completely stopped.

Vehicles with a keyless access with push button start
system
While the push-button ignition switch is in “ON” mode,
move the select lever with the brake pedal depressed.

When shifting the select lever between P and D, make sure that
the vehicle is completely stopped.

∗

: If equipped

186

2-1. Driving procedures

BRZ_U

■

Shift position uses

*

: Shifting to the D position allows the system to select a gear suitable for

the driving conditions. Setting the select lever to the D position is rec-
ommended for normal driving.

Shift

position

Multi-information display

Function

Monochrome

display

Color display

P

Parking the vehicle/start-

ing the engine

R

Reversing

N

Neutral

D

Normal D position driving

*

(gears between “1” and “6”

are automatically

selected)

(paddle shift levers

activated)

(paddle shift levers

activated)

Temporary manual mode

driving

(

→P. 190)

M

Manual mode driving

(

→P. 188)

187

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

■

Selecting a driving mode
By pressing the driving pattern selector switch the following
modes can be selected to suit driving and usage conditions:

Normal mode
Sport mode

The “SPORT” indicator comes on.

Use sport mode for sporty driving or when driving in mountainous
regions with lots of curves.

Snow mode

The “SNOW” indicator comes on.

Use snow mode for accelerating and driving on slippery road surfaces
such as snow.

To cancel sport mode or snow mode, press the same side of the switch
again.

188

2-1. Driving procedures

BRZ_U

Manual mode driving

To enter manual mode, shift the select lever to the M position.

While the upshift/downshift indicator light is illuminated, gears can be
selected by operating the select lever or paddle shift levers, allowing
you to drive in the gear of your choosing.

Even if upshifting operations are performed, if vehicle speed is too low for
the requested gear, the gear will not change.

Upshift indicator
Downshift indicator
Upshifting (+)
Downshifting (-)

Each time the select lever or
paddle shift levers are operated,
the gear changes up or down
one gear and the selected gear,
“1” through “6”, will be set.

The selected gear, from “1” to “6”,
and “M” will be displayed on the
shift position and shift range indi-
cator.

*

1

: Vehicles with a monochrome multi-information display

*

2

: Vehicles with a color multi-information display

When in manual mode, the gear will not change unless the select
lever or paddle shift levers are operated.

*

1

*

2

189

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

However, even when in manual mode, the gears will be automatically
changed in the following situations:

● When vehicle speed drops (downshift only).
● When engine oil temperature is high and engine speed rises close

to the red zone.

■

When moving the select lever out of P

If the select lever is pushed sideways before the brake pedal is depressed,
select lever operation may not be possible. Depress the brake pedal before
shifting the select lever out of P.

■

Downshifting restrictions warning buzzer

If downshifting operations are performed at a vehicle speed by which down-
shifting is not possible (when downshifting will cause the engine speed to
enter the red zone), a buzzer will sound to warn the driver that downshifting
cannot be performed.

■

When driving with cruise control activated

Downshifting can be performed even when using cruise control. After down-
shifting, the set speed continues. (

→P. 188, 190)

■

Sport mode

●

In sport mode, lower gears are used and gears change at a higher
engine speed.

●

If sport mode is changed to while the select lever is in the M position, the
“SPORT” indicator will come on but sport mode controls will not be car-
ried out. Shift the select lever to the D position.

●

Sport mode cannot be changed to when driving with cruise control acti-
vated.

■

Snow mode

To prevent slipping, 1

st

 gear cannot be selected when in snow mode.

■

Sport mode and snow mode automatic deactivation

In the following situations, the driving mode is automatically deactivated:

●

When the engine is turned off after driving in sport mode or snow mode.

●

When cruise control is activated while driving in sport mode.

190

2-1. Driving procedures

BRZ_U

■

If the select lever cannot be shifted from P
→P. 468

■

Automatic gear selection when the vehicle is stopped

When the vehicle is idling at high rpm in order to warm up, and the vehicle is
on a slippery road, the transmission may automatically shift to 2

nd

 gear for

stopping and starting off.

■

Temporary manual mode driving

*

1

: Vehicles with a monochrome multi-information display

*

2

: Vehicles with a color multi-information display

Temporary manual mode driving will be deactivated and normal D position
driving will be returned to in the following situations:

●

When driving for longer than the set time (the set time differs according
to driving conditions).

●

When the vehicle comes to a stop.

●

When the accelerator pedal is continually depressed for longer than the
set time.

●

When the accelerator pedal is fully, or near-fully, depressed.

Temporary manual mode driving can be
changed to by operating the paddle shift
levers while the select lever is in the D
position.

When this occurs, the selected gear and
“D” are displayed on the shift position and
shift range indicator.

(When engine speed rises close to the
red zone, upshifting will be automatically
performed.)

*

1

*

2

191

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

■

Adaptive control

In order to realize smoother driving while driving in D position, an appropri-
ate gear is automatically selected by limiting upshifting and performing
downshifting operations according to driver operations and driving condi-
tions.

●

When driving uphill, prevents unnecessary upshifting and downshifting.

●

When driving downhill, downshifting is performed at engine speeds
higher than usual.

●

When driving on curves, prevents upshifting even when accelerating.

●

When the brake pedal is depressed firmly, downshifting is automatically
performed, fully utilizing engine braking.

●

When the accelerator pedal is suddenly released, prevents upshifting.

Adaptive control operates automatically when the select lever is in the D
position. (The function is canceled when the paddle shift levers are operated
or the select lever is shifted to the M position.)

WARNING

■

When driving on slippery road surfaces

Be careful of downshifting and sudden acceleration, as this could result in
the vehicle skidding to the side or spinning.

■

To prevent incorrect operation

Do not attach items such as accessories to the paddle shift levers.
Doing so may unintentionally move the paddle shift levers.

192

2-1. Driving procedures

BRZ_U

Manual Transmission

∗

∗

: If equipped

■

Shifting the shift lever

Fully depress the clutch pedal before operating the shift lever, and
then release it slowly.

■

Shifting the shift lever to R

Shift the shift lever to R while
lifting up the ring section.

193

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

Shift position indicator

The selected shift position will be
displayed on the multi-informa-
tion display.

The selected shift position will not
appear in the following situations:

• When the shift lever is in neu-

tral.

• When the vehicle speed is 6

mph (10 km/h) or less (except
when the shift lever is in R).

• When the clutch pedal is

depressed.

The default setting of the indicator
is off. The indicator can be turned
on/off. (

→P. 214, 228)

*

1

: Vehicles with a monochrome multi-information display

*

2

: Vehicles with a color multi-information display

Shift-up indicator

To help enable fuel-efficient driv-
ing, the shift-up indicator flashes
3 times to indicate upshift timing.

The default setting of the indicator
is off. The indicator can be turned
on/off. (

→P. 214, 228)

*

1

: Vehicles with a monochrome multi-information display

*

2

: Vehicles with a color multi-information display

*

1

*

2

*

1

*

2

194

2-1. Driving procedures

BRZ_U

CAUTION

■

To prevent damage to the transmission

●

Do not lift up the ring section except when shifting the lever to R.

●

Shift the shift lever to R only when the vehicle is stationary and the clutch
pedal is fully depressed.

●

Do not shift the shift lever without
depressing the clutch pedal.

195

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

Turn signal lever

The turn signal lever can be used to show the following intentions of
the driver:

Right turn
Left turn
Lane change to the right
(move the lever partway
and release it)

The right hand signals will
flash 3 times.

Lane change to the left
(move the lever partway
and release it)

The left hand signals will flash
3 times.

196

2-1. Driving procedures

BRZ_U

■

Turn signals can be operated when

Vehicles without a keyless access with push button start system
The engine switch is in the “ON” position.

Vehicles with a keyless access with push button start system
The push-button ignition switch is in “ON” mode.

■

If the indicators flash faster than usual

Check that a light bulb in the turn signal lights has not burned out.

■

If the turn signals stop flashing before a lane change has been per-
formed

Operate the lever again.

■

To discontinue flashing of the turn signals during a lane change

Operate the lever in the opposite direction.

■

Customization that can be configured at your SUBARU dealer

The lane change turn signal function can be disabled.
(Customizable features:

→P. 515)

197

2-1. Driving procedures

2

Wh
en driv

in

g

BRZ_U

Parking brake

■

Usage in winter time
→P. 274

CAUTION

■

Before driving

Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating, which may affect braking performance and increase brake
wear.

To set the parking brake, fully pull the parking brake lever while
depressing the brake pedal.
To release the parking brake, slightly raise the lever and lower it
completely while pressing the button.

U.S.A.

Canada and

Mexico
