EN(H4SO 2.5)(diag)-201
ENGINE (DIAGNOSTICS)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step
Check
Yes
No
1
CHECK OPTION CODE.
Is the option code EC, EK, EH,
ER or K4?
Go to step 2.
Refer to EN(H4SO
2.0) section. <Ref.
to EN(H4SO
2.0)(diag)-64, List
of Diagnostic Trou-
ble Code (DTC).>
NOTE:
Fuel injection sys-
tem for KA and KS
model is the same
as 2.0 L model.
2
CHECK OPERATION OF STARTER MOTOR.
Turn the ignition switch to START.
NOTE:
• For AT model, set the selector lever in the
“P” or “N” range.
• For MT model, depress the clutch pedal.
Does the starter motor oper-
ate?
Repair the har-
ness and connec-
tor.
NOTE:
In this case, repair
the following:
• Open or ground
short circuit of har-
ness between
ECM and starter
motor connector
• Poor contact in
ECM connector
Check the starter
motor circuit. <Ref.
to EN(H4SO
2.5)(diag)-54,
STARTER
MOTOR CIRCUIT,
Diagnostics for
Engine Starting
Failure.>
