ABS AND TCS 4E-87
SSANGYONG Y200
Yes
Step
Use the scan tool to determine if any other DTCs are
set.
Are other DTCs set?
Clear all DTCs and road test the vehicle.
Does DTC 550 set again?
1. Check all wiring harness connectors and terminals,
especially those at the EBCM, for any condition
that could cause an intermittent.
2. Repair any problems found.
Is the repair complete?
1. Turn the ignition to OFF.
2. Disconnect the EBCM connector.
3. Turn the ignition to ON.
4. Measure the voltage between ground and terminals
15, 17 and 18 of the EBCM harness connector.
Is the voltage equal to the specified value?
1. Check the voltage supply and the ground
connections to the EBCM.
2. Repair any open or high resistance found.
Is the repair complete?
Check the EBCM connector for any damaged
terminals.
Are there any problems?
Repair any connector problem found.
Is the repair complete?
Clear all DTCs and road test the vehicle.
Does DTC 550 set again?
Replace the EBCM.
Is the repair complete?
DTC 550 - EBCM Internal Fault
1
Action
No
Value
2
3
Go to the
applicable
Diagnostic
Table
Go to Step 2
-
4
5
6
System OK
-
-
System OK
-
-
Go to Step 4
Go to Step 3
-
Go to Step 6
Go to Step 5
11 - 14 V
Go to Step 7
Go to Step 8
-
7
System OK
-
-
Go to Step 9
System OK
-
System OK
-
-
8
9
