TIRES AND WHEELS  2E-5

SSANGYONG  Y200

Wheel

Tire

Wheel Alignment

Size

Type

Inflation Pressure (psi)

Toe-in

Camber

Caster

SPECIFICATIONS

2 ± 2 mm

0° ± 30’ (Below 30' the difference between right and left)

2° 45 ± 30’ (Below 30' the difference between right and left)

Aluminum Type

Steel Type

Aluminum Wheel

Steel Wheel

Radial Tire

P225/75R15

P235/70R16

P255/65R16

7JJ x 16

6.5JJ x 16

8 - 12 kgf.m

11 - 13 kgf.m

Radial Tire

30 psi

30 psi

30 psi

Wheel Nut Tightening
Torque

SSANGYONG  Y200

2E-6  TIRES AND WHEELS

DIAGNOSTIC INFORMATION AND PROCEDURES

Adjust

Adjust

Rotation tires on the maintenance
schedule

Adjust

Adjust

Adjust

Adjust

Adjust

Adjust or replacement

Check and adjust

Adjust

Adjust

Proper weight

Action

Irregular tires wear

Driving noise, Vibration

Rapid wear

Condition

Improper tire inflation pressure

Poor wheel balance

Improper tire rotation

Poor toe-in

Poor adjusting the pre-load of the wheel bearing

Poor braking performance

Low tire inflation pressure

Poor balance of wheels, tires

Severe vibration due to wheels, tires

Irregular tires wear

Excessive tire inflation pressure

High speed driving with low tire pressure

Excessive vehicle weight

Cause

TIRES AND WHEELS  2E-7

SSANGYONG  Y200

GENERAL INSPECTION

INSPECTION THE APPEARANCE

Adjust inflation
pressure

Action

Rapid wear at
shoulders

Condition

Under inflation or lack of rotation

Cause

Rapid wear at center

Over inflation or rotation

Tread damage

Low the inflation pressure

Adjust camber

Uneven wear

Incorrect camber

Incorrect toe-in

YAD2E100

YAD2E110

YAD2E120

YAD2E130

YAD2E140

YAD2E150

YAD2E160

YAD2E110

SSANGYONG  Y200

2E-8  TIRES AND WHEELS

Inspection The Appearance (Cont’d)

Adjust toe-in

Action

Feathered edge

Condition

Incorrect toe-in

Cause

Bold spot

Unbalanced wheel

Sharply wear at the tread outside

Unbalanced wheel

Wheel bearing play

Ball joint play

Faulty shock absorber

YAD2E170

YAD2E180

YAD2E190

YAD2E200

YAD2E210

Adjust wheel balance

Adjust

Check play

Check pre-load

Check

Check
