ELECTRICAL WIRING DIAGRAMS 5-57
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Main - Floor (LH)
Main - Floor (LH)
Main - Diagnosis Connector
Floor - T/M
W/H Main
W/H Engine
C208 (20Pin, Black)
C209 (22Pin, Yellow)
C211 (18Pin, White)
C901 (12Pin, White)
S207 (14Pin, Black)
G103
Connecting Wiring
Harness
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Upper the Diagnosis
Left the T/C (Under the Floor)
Behind the Right FATC
Behind the Left Head Lamp
XDi
XDi
Tail Lamp
Remark
Connector Position
