SSANGYONG REXTON XDi(RHD) 2-6 POSITION OF CONNECTORS AND GROUNDS 2) SPLICE PACK Connector Number (Pin Number, Color) OVPR “6” - Injector OVPR “8” - IGN Coil OVPR “2” - HFM/CPS W/H Main W/H Main W/H Main W/H Main W/H Main W/H Main W/H Main W/H Main W/H Main W/H Floor W/H Floor W/H Floor S101(7Pin, -) S102(4Pin, -) S103(4Pin, -) S201(14Pin, Black) S202(14Pin, Black) S203(14Pin, Black) S204(14Pin, Black) S205(14Pin, Black) S206(14Pin, Black) S207(14Pin, Black) S208(14Pin, Black) S209(14Pin, Black) S301(8Pin, Black) S301A(8Pin, Black) S302(14Pin, Black) Connecting Wiring Harness Inside the C113, C114 Inside the Injector “6” Inside the C113, C114 Upper the I/P Relay Box Upper the I/P Relay Box Upper the I/P Relay Box Behind the Left FATC Behind the Left FATC Behind the Left FATC Behind the Right FATC Behind the Right FATC Behind the Left FATC Under Driver Seat Under Driver Seat Under Driver Seat GSL GSL GSL GND GND GND Tail Lamp XDi CAN(GSL) XDi Remark Connector Position |
