INTERIOR TRIM 9G-5 SSANGYONG MY2002 E F KAA9G060 KAA9G050 A-PILLAR TRIM PANEL Removal and Installation Procedure 1. Remove the roof assist handle with the screws. 2. Remove the A-pillar trim panel. 3. Installation should follow the removal procedure in the reverse order. 6. Disconnect the electrical connector. 7. Remove the door trim panel. 8. Installation should follow the removal procedure in the reverse order. KAA9G080 KAA9G070 3. Remove the upper quarter trim panel. 4. Installation should follow the removal procedure in the reverse order. UPPER QUARTER TRIM PANEL Removal and Installation Procedure 1. Remove the roof assist handle with the screws. 2. Remove the seat belt anchor with the bolt. Installation Notice • Dissimilar metals in direct contact with each Tightening Torque 45 N•m (33 lb-ft) |
