Renault Megane Sport Tourer (2016 year). Manual

1.2

RENAULT CARDS: general information

(1/2)

1 Unlocking the doors and tailgate.

2 Locking all doors and tailgate.

3 Switching on the lighting remotely.

4 Unlocking/locking the tailgate

5 Integrated key.

The RENAULT card is used

for:

– locking/unlocking the doors and tail-

gate (doors, tailgate) and the fuel

filler flap (see the following pages);

– switching on the vehicle lighting re-

motely (refer to the following pages);

– depending on the vehicle, automati-

cally closing the electric windows

and sunroof remotely (see the infor-

mation on “Electric windows/Electric

sunroof” in Section 3);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“Keycard battery low” appears on the

instrument panel (refer to the informa-

tion on the “RENAULT card: battery” in

section 5).

RENAULT card operating

range

This varies according to the surround-

ings. It is important to make sure when

handling the RENAULT card that you

do not lock or unlock the doors by inad-

vertently pressing the buttons.

When the battery is flat, you can

still lock/unlock and start your ve-

hicle. Refer to the information on

“Locking/unlocking the doors” in

Section 1 and “Starting the engine”

in Section 2.

Driver’s responsibility

Never leave your vehicle

with the RENAULT card

inside and never leave a

child (or a pet) unsupervised, even

for a short while.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.

Risk of serious injury.

1 2 3

1.3

RENAULT CARDS: general information

(2/2)

Integrated key 5

The integrated key is used to lock or

unlock the front left-hand door if the

RENAULT card does not work:
– when the RENAULT card battery is

drained, flat battery, etc.

– use of devices using the same fre-

quency as the card;

– vehicle located in a high electromag-

netic radiation zone.

Access to key 5
Press button 6 and pull on key 5 then

release the button.

Using the key
Refer to the information on “Locking/

unlocking the doors”.
Once you have accessed the vehicle

using the integrated key, replace it

in its housing in the RENAULT card,

then insert the RENAULT card into

the card reader to start the vehicle.

Advice
Avoid leaving the card in hot, cold or

humid areas.
Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

Replacement: need for an

additional RENAULT Card
If you lose your RENAULT card or

require another, you can obtain one

from an approved dealer.
If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards

to an approved dealer to initialise

the system.
You may use up to four RENAULT

cards per vehicle.

1.4

REMOTE CONTROL RENAULT CARD: use

Unlocking the doors and

tailgate

Press button 1.

The hazard warning lights flash once

to indicate that the doors have been un-

locked.
When unlocking is only active for the

driver’s door, (refer to the information

on the “vehicle settings customisation

menu” in Section 1):

– pressing button 1 unlocks only the

driver’s door and the fuel filler flap;

– pressing button 1 twice unlocks all

the doors and the tailgate.

Locking the doors and

luggage compartment

Press the locking button 2. The hazard

warning lights flash twice to indicate

that the doors have locked. If a door

or the luggage compartment is open

or not properly shut, or if a RENAULT

card is still in the reader, the doors and

luggage compartment lock then quickly

unlock and the hazard warning lights

do not flash.

Unlocking/locking the

luggage compartment only

Press button 4 to unlock/lock the lug-

gage compartment.

RENAULT card not detected

alarm

If you open a door while the engine

is running and the card is not in the

reader, the message “Keycard not de-

tected” and a beep will warn you. The

warning disappears when the card is in-

serted in the reader again.

Distance lighting function

The dipped beam headlights, indicator

lights and interior lights come on for ap-

proximately 30 seconds when button 3

is pressed. This can be used, for exam-

ple, to identify the vehicle from a dis-

tance when parked in a car park.

Note: pressing button 3 again switches

off the lighting.

The card buttons are deactivated

when the engine is running.
The flashing status of the hazard

warning lights informs you of the ve-

hicle status:
– one flash indicates that the vehi-

cle is completely unlocked;

– two flashes indicate that the ve-

hicle is completely locked.

If the vehicle has been unlocked

but neither the doors or tailgate are

open, it locks again automatically

after two minutes.

1.5

RENAULT “HANDS-FREE” CARD: use

(1/3)

After unlocking the vehicle or the

boot only using the buttons of the

RENAULT card, remote locking and

unlocking in hands-free mode are

deactivated.
To reactivate the hands-free mode:

restart the vehicle.

Use

On equipped vehicles, in addition to

the functions of the above-mentioned

remote control RENAULT card, it can

be used to lock/unlock without using

the RENAULT card, when it is in access

zone 1.

Recommendations
Do not store the RENAULT card

anywhere it may come into con-

tact with other electronic equipment

(computer, PDA, phone, etc.) as this

could hinder its operation.

Unlocking the vehicle

RENAULT card in area 1, press the 3

button: the vehicle will unlock.
In some cases (leaving the vehicle

parked for several days, for example),

you may need to pull handle 2 twice to

unlock the vehicle and open the door.
Pressing the button 4 also unlocks all

the doors and the tailgate.
The hazard warning lights flash once

to indicate that the doors have been un-

locked.

1.6

RENAULT “HANDS-FREE” CARD: use

(2/3)

Locking the vehicle

There are three ways to lock the ve-

hicle: remotely, using the button 3, or

using the RENAULT card.

Remote locking

With the RENAULT card on you, and

doors and tailgate closed, move away

from the vehicle: it will lock automati-

cally once you have left zone 1.
Note: the distance at which the vehicle

locks depends on the surroundings.

The hazard warning lights flash twice

and a beep sounds to indicate that the

doors have locked.

The beep may be switched off. Please

contact an authorised dealer.

If a door or the tailgate is open or not

properly shut, or a card is in the passen-

ger compartment (or the card reader)

the vehicle will not lock. In this situa-

tion, no beep sounds and the hazard

warning lights do not flash.

Locking using the button 3
With the doors and boot closed, press

the button 3 on a door handle of the ve-

hicle: the vehicle will lock. If a door or

the boot is open or not closed properly,

the vehicle will quickly lock/unlock.
Note: a RENAULT card must be within

the vehicle's access zone (zone 1) to

be able to lock the vehicle using the

button.
Special note
If you wish to check that the doors are

locked after locking using the button 3,

you have approximately three seconds

to try the door handles without unlock-

ing them.
After this delay, the hands-free mode

is activated once again and any move-

ment of a handle will unlock the vehicle.

If the vehicle is fitted with remote window closing, two quick presses on the button 3 automatically causes all the windows to

close and the doors to lock (please see the information on “Electric windows, Electric sunroof” in Section 3).

1.7

With the engine running, if having

once opened and closed a door, the

card is no longer in the passenger com-

partment, the message “Keycard not

detected” (accompanied by a warning

beep once the speed passes a thresh-

old value) will tell you that the card is no

longer in the vehicle. This avoids you

driving away after having dropped off a

passenger who has the card, for exam-

ple.
The warning disappears when the card

is detected again.

RENAULT “HANDS-FREE” CARD: use

(3/3)

Locking using the RENAULT card
With the doors and luggage compart-

ment closed, press button 5: the vehi-

cle will lock.
The hazard warning lights flash twice

to indicate that the doors have locked.
Note: the maximum distance at which

the vehicle locks depends on the sur-

roundings.

Special features
The vehicle will not lock if:
– a door or the tailgate is open or not

properly closed;

– a card is still in zone 6 (or in the card

reader) and no other card is in the

external detection zone.

After locking/unlocking the vehicle

or the luggage compartment only

using the buttons on the RENAULT

card, remote locking and unlocking

in hands-free mode are deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

1.8

To deactivate deadlocking

Unlock the vehicle using button 1 on

the RENAULT card.
The hazard warning lights flash once to

indicate that the doors have been un-

locked.

Never use deadlocking if

someone is still inside the

vehicle.

To activate deadlocking

You can choose between two deadlock- -

ing activation modes:
– press button 2 twice in quick succes-

sion;

– or, press twice in quick succession

on the button 3 of the handle on one

of the vehicle’s doors.

The hazard warning lights flash five

times to indicate locking.

If the vehicle is equipped with a dead-

locking function, this allows you to lock

the opening elements and to prevent

the doors from being unlocked using

the interior handles (for example, by

breaking the window and then trying to

open the door from the inside).

RENAULT CARD: deadlocking

Activating deadlocking also re-

motely closes the windows and/or

the electric sunroof, on equipped

vehicles.
After activating the deadlocking

function using button 2, remote

locking and unlocking in hands-free

mode are deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

1.9

OPENING AND CLOSING THE DOORS

(1/2)

Opening from the inside

Pull the handle 3.

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened.

Card reminder buzzer

On opening the driver’s door, if the

card is still in the reader, the message

“Please remove keycard” is displayed

on the instrument panel accompanied

by a warning beep.

Door/tailgate open buzzer

If an opening element (door or boot) is

open or not properly closed, as soon as

the vehicle reaches a speed of approxi-

mately 6 mph (10 km/h), the message

“Boot open” or “Door open” (depend-

ing on which is open) will appear on the

instrument panel accompanied by a

warning light.

Special note
After switching off the engine, the lights

and any accessories that are in opera-

tion (radio, etc.) will continue to oper-

ate.
They stop as soon as the driver’s door

is opened.

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Opening the doors from the

outside

RENAULT card
With the doors unlocked, hold handle 1

and pull it towards you.

Hands-free RENAULT card
With the RENAULT card in the detec-

tion zone, press the button 2 or, de-

pending on the vehicle, put your hand

round the handle 1, then grip it and pull

towards you.
In some cases, it may be necessary to

pull the handle twice to open the door.

1.10

OPENING AND CLOSING THE DOORS

(2/2)

Child safety

To make it impossible for the rear doors

to be opened from the inside, move

lever 4 on each door and check from

the inside that the doors are securely

locked.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.11

LOCKING/UNLOCKING THE DOORS

(1/2)

Locking/Unlocking the doors

from the outside

This is done using the RENAULT Card;

see the “RENAULT Card” information in

Section 1.
In certain cases, the RENAULT card

may not work:
– if the RENAULT card battery is weak,

flat, etc.

– if equipment operating on the same

frequency as the card (mobile

phones, etc.) is used;

– vehicle located in a high electromag-

netic radiation zone.

It is then possible:
– to use the key integrated into the

card to unlock the front left-hand

door;

– to lock each of the doors manually;
– to use the interior door locking/un-

locking control (refer to the following

pages).

Using the key integrated in

the RENAULT card

– Remove cover A from the left-hand

door (using the end of key 2) in

notch 1;

– move it upwards to remove cover A;
– insert the key 2 into the lock of the

front left-hand door and lock or

unlock.

Locking the doors manually

Turn screw 3 with the door open (using

the end of the key) and close the door.
This means that the doors are then

locked from the outside.
The doors may then only be opened

from the inside or by using the key in

the front left-hand door.

1.12

LOCKING/UNLOCKING THE DOORS

(2/2)

Interior locking/unlocking

door control

Switch 4 controls the doors, tailgate

and, depending on the vehicle, the fuel

filler flap simultaneously.
If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.
If transporting an object with the tail-

gate open, you can still lock the doors:

with the engine stopped, press and

hold switch 4 for more than five sec-

onds to lock the other doors.

Locking the doors without

the RENAULT card

For example, in the event of a dis-

charged battery or the RENAULT card

temporarily not working, etc.
With the engine switched off and a

door or tailgate open, press and hold

switch 4 for more than five seconds.
When the door is closed, all the doors

and the tailgate will be locked.
Unlocking the vehicle from the outside

is only possible with the RENAULT card

in the vehicle's access zone or using

the key integrated in the RENAULT

card.

Door and tailgate status

indicator

When the ignition is on, the indicator

light integrated in switch 4 informs you

of the status of the doors and tailgate:
– indicator light on, the doors and tail-

gate are locked,

– indicator light off, the doors and tail-

gate are unlocked.

When you lock the doors, the indicator

light remains lit and then goes out.

Never leave your vehicle

with the RENAULT card

inside.

After locking/unlocking the vehicle

or the tailgate only using the but-

tons on the RENAULT card, remote

locking and unlocking in hands-free

mode are deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.13

Activating/deactivating the

function

Refer to “Vehicle settings customisation

menu” in Section 1, regarding the “Auto

door locking while driving” function:

function activated

function deactivated.

AUTOMATIC LOCKING WHEN DRIVING

You can decide whether you want to

activate this function.

Operating principle

After the vehicle is started, the system

automatically locks the doors when

you are driving at approximately 6 mph

(10 km/h) and over.
The door can be unlocked:
– by pressing the door unlocking

button 1.

– by opening a front door (vehicle sta-

tionary).

Note: if a door is opened or closed,

it will automatically lock again when

the vehicle reaches a speed of 6 mph

(10 km/h).

Operating faults

If you experience an operating fault (no

automatic locking, the indicator light in-

corporated in button 1 does not light up

when trying to lock the doors and tail-

gate, etc.), firstly check that the doors

and tailgate are properly closed. If they

are closed correctly, contact an ap-

proved dealer.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.14

FRONT HEADRESTS

To raise the headrest

Pull the headrest upwards to the de-

sired height.

To lower the headrest

Press button 2 and guide the headrest

down to the desired height.

To adjust the angle of the

headrest

Depending on the vehicle, tilt section A

towards or away from you to the re-

quired position.

To remove the headrest

Raise the headrest to its highest po-

sition (tilt the seatback backwards if

necessary). Press button 1 and lift the

headrest to release it.

To refit the headrest

Pull out the headrest rods 3 as far as

possible by pulling from the top. Take

care to ensure they are clean and cor-

rectly aligned and, if there are any prob-

lems, check that the notches are facing

forwards.

Insert the headrest rods into the holes

(tilt the seatback backwards if neces-

sary).

Lower the headrest until it locks, press

button 1 and lower the headrest as far

as possible.

Check that each headrest rod 3 is se-

curely locked in the seatback by trying

to pull them up or push them down.

The headrest is an impor-

tant safety component:

ensure that it is in place and

in the correct position. The

distance between your head and the

headrest and the distance between

the head and section A should be

as small as possible.

The three upper positions can

be manipulated without pressing

button 2. However, it is preferable to

press this button to lower the head-

rest.

1.15

REAR HEADRESTS

Position for use

Raise or lower the headrest while pull-

ing it towards the front of the vehicle.

To remove the headrest

Press tabs A of rods 1 and 2 simultane-

ously and remove the headrest.
Note: on the three door version, first

lower the bench seatback (refer to the

information on the “Rear seat functions”

in Section 3).

To refit the headrest

Insert the headrest rods into the

sleeves, and lower the headrest to the

first notch.

Storage position

Lower the headrest as far as possi-

ble, then press tab 2 and lower it com-

pletely.
When the headrest is set at the

lowest position (position B) this is

for storage only: it should not be in

this position when a seat is occupied.

The headrest is a safety

component. Ensure that it is

fitted and in the correct po-

sition: the top of your head

should be in line with the top of the

headrest.

1.16

FRONT SEATS WITH MANUAL CONTROL

(1/2)

To move the seat forwards or

back

Lift handle 1 to release. Release the

handle once the seat is in the correct

position and ensure that the seat is fully

locked into position.

To raise or lower the seat

base

Move lever 2 as many times as neces-

sary upwards or downwards.

To tilt the seatback

Turn control knob 3 to the required po-

sition.

Heated seats

(depending on vehicle)
With the engine running, turn control 4

to either position I, II or III (depending

on the temperature required). The

message "Heated seat activated» will

appear on the instrument panel once

one of the front seat heating systems

is operating.

The system, which has a thermostat,

decides whether or not the heating is

needed, according to the position se-

lected.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

We would advise you not to recline

the seatbacks too far to ensure that

the effectiveness of the seat belts is

not reduced.
Nothing should be placed on the

floor (area in front of driver) as such

objects may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

1.17

Table function

Depending on the vehicle, the passen-

ger seatback may be folded down onto

the seat base to create a table.
Lower the headrest, move the seat

back, tilt handle 6 and completely lower

the seatback.

For your safety, attach any

transported objects when

the seat is in the table po-

sition.

FRONT SEATS WITH MANUAL CONTROL

(2/2)

To adjust the lumbar support

on the driver’s seat

Lower handle 5 to increase the support

and lift to decrease it.

When the front seat is in

table position, the front pas-

senger air bag must be di-

sabled (see information on

“Child safety: activating/deactiva-

ting the front passenger air bag” in

Section 1).
Risk of serious injury caused by

items resting on the seatback table

which may be dislodged when the

air bag is deployed.
The label (on the dashboard) and

the markings (on the windscreen)

remind you of these instructions.

Renault Megane Sport Tourer (2016 year). Manual - part 1
