Renault Kadjar (2018 year). Manual

2.44

LANE DEPARTURE WARNING

(1/3)

This function is a driving aid in the event of the accidental crossing of

a continuous or broken line in the road. However, the function is not in-

tended to replace the driver. The function can be disrupted under certain

conditions, including:

– poor visibility (rain, snow, fog, dirty windscreen, glare of the sun, partially ob-

scured road lines, etc.);

– roads with tight bends;

– closely following a vehicle in the same lane;

– worn road markings, difficult to distinguish or spaced very widely apart;

– narrow roads;

– ...
In this case, the line visibility indicators remain uncoloured on the instrument

panel to indicate that the function will not operate (lines not detected).
Under no circumstances should this function replace the driver’s care or respon-

sibility whilst performing manoeuvres.

This system notifies the driver when

they accidentally cross a continuous or

broken line.

This function uses a camera attached

to the windscreen, behind the rear-view

mirror.

2.45

LANE DEPARTURE WARNING

(2/3)

The function is set to notify the

driver if:

– the vehicle speed is greater than ap-

proximately 45 mph (70 km/h);

and

– lines are detected and the visibility

indicators 4 are green.

The function triggers an alert if a line

is crossed without the direction indica-

tors being activated. The function alerts

the driver through a beep and the indi-

cator the line crossed switches to red

on the instrument panel.

Activation/deactivation

Vehicles fitted with a navigation

system
From the multifunction screen 2: select

“Vehicle”, “Driving assistance”, “Lane

departure warning” then choose “ON”

or “OFF”.

Vehicles not fitted with a navigation

system
Press the switch 3.

Operation

With the function activated, the grey

visibility indicators 4 for the left and

right lines are displayed on the instru-

ment panel.

You can access menu “Driving as-

sistance” directly from button 1



2.46

Adjustment

Vehicles fitted with a navigation

system
From the multifunction screen 2, select

“Vehicle”, “Driving assistance”, “Lane

departure warning settings”.

– Volume: adjust the alert volume to

one of five levels;

– sensitivity: adjust the sensitivity level

for line detection. To do this select:

– “Low” line detected upon cross-

ing;

– “Average” line detected on ap-

proach;

– “high” line detected nearby.

Vehicles not fitted with a navigation

system
– With the vehicle at a standstill, press

and hold the switch 5 OK to access

the settings menu;

– repeatedly press the control 6 up or

down until you reach the “Driving as-

sistance” menu. Press the switch 5

OK;

– repeatedly press control 6 up or

down until you reach the “Lane de-

parture warning settings” menu, then

press the switch 5 OK.

– Volume: adjust the alert volume to

one of three levels;

– sensitivity: adjust the sensitivity level

for line detection. To do this select:

– “Low” line detected upon cross-

ing;

– “Average” line detected on ap-

proach;

– “high” line detected nearby.

Operating faults

In the event of a malfunction, a mes-

sage “Lane departure warning check” is

displayed on the instrument panel, and

the visibility indicators for the left and

right lines disappear from the instru-

ment panel.

Consult an approved dealer.

LANE DEPARTURE WARNING

(3/3)

Conditions for non-activation

of alerts

– Direction indicators activated for less

than around 2 seconds prior to de-

parting from the lane;

– very fast lane departure;

– driving continuously on a line;

– on bends, the function allows for

slightly cutting the bend;

– hazard warning lights activated;

– ...

2.47

BLIND SPOT WARNING

(1/4)

This system alerts the driver to other

vehicles in the detection zone A.
The system is activated when the vehi-

cle’s speed is between approximately

30 km/h (19 mph) and 140 km/h

(87 mph).
This function uses sensors 1 installed

in the front and rear bumper of both

sides.

Special feature

Make sure that the sensors are not ob-

scured (by dirt, mud, snow, etc.).

If a sensor is obscured, the message

“Blind spotclean sensor” will appear on

the instrument panel. Clean the sen-

sors.

This function is an addi-

tional aid which indicates

other vehicles in the blind

spot area.

It can never in any case be a subs-

titute for care nor for the driver’s

responsibility while in charge of his

vehicle.
The driver should always look out

for sudden hazards during driving:

make sure while manoeuvring that

there are no moving or movable ob-

jects (such as a child, an animal, a

pushchair or a bicycle) or small or

narrow obstacles (such as a boulder

or a post) in the blind spot area.

2.48

Activation/deactivation

Vehicles fitted with a navigation

system
On the multifunction screen 3, select

the “Vehicle” menu, “Driving assist-

ance”, and “Driving assistance”, and

then choose “ON” or “OFF”.

You can access menu “Driving as-

sistance” directly from button 2



Vehicles not fitted with a navigation

system
– With the vehicle at a standstill, press

and hold the switch 4 OK to access

the settings menu;

– repeatedly press the control 5 up or

down until you reach the “Driving as-

sistance” menu. Press the switch 4

OK;

BLIND SPOT WARNING

(2/4)

– repeatedly press control 5 up or

down until you reach the “Blind spot

alert” menu, then press the switch 4

OK.

– Press the switch 4 OK again to acti-

vate or deactivate the function.

When the engine is started, the system

remembers its position when the igni-

tion was last switched off.

2.49

BLIND SPOT WARNING

(3/4)

Operation

This function will indicate:
– when the vehicle speed is between

approximately 30 km/h (19 mph) and

140 km/h (87 mph);

– when another vehicle is in the blind

spot area and travelling in the same

direction as your vehicle.

If another vehicle is being overtaken,

the indicator 4 will be activated only if

that vehicle remains in the blind spot for

more than one second.

Indicator 4

An indicator light 4 is located on each

door mirror 5.
Note: Clean the door mirrors 5 regu-

larly, so that the indicator lights 4 can

be seen properly.

Display B

The function is activated and has not

detected any vehicles.

Display C

Initial warning: the indicator light 4

shows that a vehicle has been detected

in the blind spot.

Display D

When the direction indicator is activa-

ted, the indicator light 4 flashes when a

vehicle is detected in the blind spot on

the side towards which you are about to

steer. If you cancel the direction indica-

tor, the function will return to the initial

warning (display C).

Note: The system’s detection range

operates according to a standard

lane width. If you are driving in

narrow traffic lanes, it may detect

vehicles in other lanes.

2.50

Operating faults

If the system detects a fault, the mes-

sage “Check blind spot alert” is dis-

played on the instrument panel. Consult

an authorised dealer.
Note: When the engine is started, the

indicator light 4 (display B) flashes

three times. It is normal.

– The system’s detection

range operates according

to a standard lane width. If

you are driving in wide traf-

fic lanes, the system might not

be able to detect a vehicle in the

blind spot.

– The system might be disrupted

momentarily if it is exposed to

strong electromagnetic waves

(as beneath high-tension power

lines) or to very poor weather

conditions (heavy rain, snow,

etc.). Remain aware of driving

conditions.

There is a risk of accidents.

BLIND SPOT WARNING

(4/4)

Because sensors have

been installed in the bump-

ers, any work (repairs, re-

placements, touching up of

paintwork) must be carried out by a

qualified professional.

Conditions for non-function

–  If the object is not moving;
–  if traffic is heavy;
–  the road is winding;
–  if front and rear sensors both detect

objects at the same time (e.g. when

passing an articulated lorry).

– ...

2.51

CRUISE CONTROL-SPEED LIMITER: speed limiter function

(1/3)

Switching on

Press switch 1 on side



. The indica-

tor light



comes on, lit orange, and

the message “Speed limiter” appears

on the instrument panel, accompanied

by dashes to indicate that the speed

limiter function is activated and waiting

to store a limited speed.

To store the current speed, press the

switch 2 on side a (+): the limited speed

will replace the dashes.

The minimum stored speed is 20 mph

(30 km/h).

Controls

1 Main “On/Off” switch.
2 Controls for:

a speed limiter activation, memory

and increase (+);

b decreasing the speed limiter (-).
3 Activation and recall of memorised

limited speed (R).

4 Speed limiter function standby (with

limited speed memory) (O).

The speed limiter function helps you

stay within the driving speed limit that

you choose, known as the limit speed.

If you wish, you can associate the

speed limiter and the “Overspeed

alert” function (please refer to the in-

formation on the “Overspeed alert”

in Section 2).

a 3

2.52

CRUISE CONTROL-SPEED LIMITER: speed limiter function

(2/3)

Exceeding the limit speed

It is possible to exceed the limit speed

at any time. To do this: press the accel-

erator pedal firmly and fully (beyond

the resistance point).
While the speed is being exceeded, the

speed limiter flashes red on the instru-

ment panel.
Then, release the accelerator: the

speed limiter function will return as

soon as you reach a speed lower than

the stored speed.

Limited speed cannot be maintained
If driving up or down a steep gradient,

the system is unable to maintain the

limited speed: the memorised speed

flashes red on the instrument panel and

a beep sounds at regular intervals to

inform you.

Varying the limit speed

The speed limiter can be changed by

repeatedly pressing the switch 2:
– side a (+) to increase the speed;
– side b (-) to reduce the speed.

Driving

When a limited speed has been stored

and this speed is not reached, driving is

similar to driving a vehicle without the

speed limiter function.
Once you have reached the stored

speed, no effort on the accelera-

tor pedal will allow you to exceed

the programmed speed except in an

emergency (refer to information on

“Exceeding the limit speed”).

The speed limiter function is

in no way linked to the brak-

ing system.

2.53

CRUISE CONTROL-SPEED LIMITER: speed limiter function

(3/3)

Recalling the limit speed

If a speed has been saved, it can be re-

called by pressing switch 3 ((R)).

Putting the function on

standby

The speed limiter function is sus-

pended when you press switch 4 (O).

In this case, the speed limit remains

stored and the message “Memorised”

accompanied by this speed appears on

the instrument panel.

Switching off the function

The speed limiter function is deacti-

vated if you press switch 1: in this case

a speed is no longer stored. The orange



warning light and message on the

instrument panel goes out to confirm

that the function is deactivated.

When the speed limiter is put on

standby, pressing side a (+) on

the switch 2 reactivates the func-

tion without taking into account

the stored speed: it is the speed at

which the vehicle is moving that is

taken into account.

a 3

2.54

Operating principle

The system detects speed limit signs

on the side of the road and displays the

speed limit.

This mainly uses information taken

from the camera 1, attached to the

windscreen behind the rear-view mirror.
Note: Make sure the windscreen is not

obstructed (dirt, ice, snow, etc.).
With the engine running, once you have

activated the system, dashes on the in-

strument panel notify the driver that the

system is running.
When a speed limit sign is detected,

this speed will replace the dashes for

a few seconds, after which the dashes

will come on again until the next speed

limit sign is detected.

OVERSPEED ALERT

(1/3)

The overspeed alert with signage panel

recognition notifies the driver that they

are exceeding the speed limit for the

section of road on which they are cur-

rently travelling.

Once the speed limiter is activated, you

can adjust the speed limiter indication

displayed by the system.
In the event of exceeding the speed

limit, the sign display is modified (the

characters change to red or the circle

around the sign flashes) no notify you.

Special situation
The system does not take into account

exceptional speed limit measures, such

as peak pollution days.

2.55

OVERSPEED ALERT

(2/3)

Activating/deactivating the

system

Vehicles fitted with a navigation

system
On the multifunction screen 2, select

the menu “Vehicle”, “Aides à la con-

duite”, “Speed alert settings”, then

choose “ON" or "OFF".

With the function activated and de-

pending on local laws, you can activate

the “increased vigilance zones”. The

system will notify you of the distance

separating you from this zone, and

while you are travelling in the zone.

Vehicles not fitted with a navigation

system

– With the vehicle at a standstill, press

and hold the switch 5 OK to access

the settings menu;

– repeatedly press the control 6 up or

down until you reach the “Aides à la

conduite” menu. Press the switch 5

OK;

– repeatedly press the control 6 up or

down until you reach the Speed alert

menu, then press the switch 5 OK.

– Press OK to turn the function on or

off.

Varying the limit speed

If the speed limiter notification differs

from the detected speed value, press

and hold the switch 4:

– side a (+) to increase the notification

speed to the detected speed;

– side b (-) to reduce the notification

speed to the detected speed.

You can access menu “Driving as-

sistance” directly from button 3



2.56

This function is an additional driving aid. However, this function is not

under any circumstances intended to replace the due care and attention

of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, re-

gardless of the system indications.
The system enables maximum speed signs to be detected and does not detect

other traffic signage.
The driver should not, however, ignore signs which are not detected by the system

and should as a priority comply with the traffic signage and the highway code.
In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system

may not indicate the correct speed to the driver.
The driver should always adapt their speed to the traffic conditions, regardless of

the system indications.

OVERSPEED ALERT

(3/3)

Operating fault

The system cannot detect the speed

limit if:
–  the windscreen is not clean;
–  the camera is blinded by the sun;
–  there is insufficient visibility (night,

fog, etc.);

– the signs are not legible (snow, etc.)

or are hidden (by another vehicle or

by trees).

2.57

CRUISE CONTROL-SPEED LIMITER: cruise control function

(1/4)

The cruise control function helps you to

maintain your driving speed at a speed

that you choose, called the cruising

speed.
This cruising speed may be set at any

speed above 20 mph (30 km/h).

The cruise control function

is in no way linked to the

braking system.

This function is an addi-

tional driving aid. However,

the function does not take

the place of the driver.

Therefore, it can under no circum-

stances replace the driver’s respon-

sibility to respect speed limits and to

be vigilant (the driver must always

be ready to brake). Cruise control

must not be used in heavy traffic, on

undulating or slippery roads (black

ice, aquaplaning, gravel) and during

bad weather (fog, rain, side winds

etc.).
There is a risk of accidents.

Controls

1 Main “On/Off” switch.
2 Controls for:

a cruising speed activation, storage

and increase (+);

b decreasing cruising speed (-).
3 Activation with recall of saved cruis-

ing speed (R).

4 Switch the function to standby (with

cruising speed saved) (O).

2.58

CRUISE CONTROL-SPEED LIMITER: cruise control function

(2/4)

Driving

Once a cruising speed is memorised

and the cruise control function is active,

you may lift your foot off the accelera-

tor pedal.

Please note that you are

strongly advised to keep

your feet close to the pedals

in order to react in an emer-

gency.

Activating cruise control

At a steady speed (above approx.

20 mph (30 km/h)), press the switch 2

on side a (+): the function is activated

and the current speed is saved.
The cruising speed replaces the dashes

and cruise control is confirmed by the

appearance of the message “Check

cruise control” and the warning light



If you try to activate the function below

20 mph (30 km/h), the message “Invalid

speed” will be displayed and the func-

tion will remain inactive.

Switching on

Press switch 1 on side



Indicator light



comes on, lit green,

and the message “Check cruise con-

trol” appears on the instrument panel,

accompanied by dashes to indicate that

the cruise control function is activated

and waiting to store a cruising speed.

2.59

CRUISE CONTROL-SPEED LIMITER: cruise control function

(3/4)

Exceeding the cruising speed

The cruising speed may be exceeded

at any time by depressing the accelera-

tor pedal. While overtaking, the cruis-

ing speed flashes red on the instrument

panel.
Then, release the accelerator: after a

few seconds, the vehicle will automati-

cally return to its set cruising speed.

Cruising speed cannot be

maintained
If driving up or down a steep gradi-

ent, the system is unable to maintain

the cruising speed: the stored speed is

flashes red on the instrument panel to

inform you of this situation.

Adjusting the cruising speed

The cruising speed can be changed by

pressing the switch 2 repeatedly:
– side a (+) to increase the speed;
– side b (-) to reduce the speed.

The cruise control function

is in no way linked to the

braking system.

Renault Kadjar (2018 year). Manual - part 10
