5.30 Operating faults If the battery is too weak to ensure cor- rect operation, you can still start (insert the RENAULT card in the card reader) and lock/unlock the vehicle (refer to the information on "Locking/unlocking the doors" in Section 1). RENAULT CARD: battery Replacing the battery When the message “KEYCARD BATTERY LOW” appears on the instru- ment panel, replace the RENAULT card battery, press button 1 pulling on emer- gency key 2, then unclip the cover 3 using tab 4. Remove the battery by pressing on one side (movement A) and by lifting the other (movement B) then replace it, en- suring the polarity and model, shown on cover 3 are respected. Do not throw away your used batteries; give them to an organisation responsible for collecting and recycling batteries. 1 2 When refitting, proceed in the reverse order, then press one of the buttons on the card four times, close to the vehicle: the next time the vehicle is started, the message will disappear. Note: it is not advisable to touch the electronic circuit or contacts on the RENAULT card when replacing the bat- tery. A B 3 The batteries are available from approved Dealers, and their service life approxi- mately two years. Check that there is no dye on the battery: risk of an incorrect electrical contact. 4 Check that the cover is clipped shut. |
