78 REAR SEAT TRIM 78-1 Remove by swinging the seats (1) and (4). (8) and (7). Detach the attachment rods (15) and (12) of the seats on the corresponding quilts and re- move the upholsters (14) and (13) from the seat quilts. Remove the front seat upholstery from the seat quilt. REMOUNTING BACK REST UPHOSTERY DISMOUNTING Dismount the backrest seats (2) and (3) from the central and lateral attachment screws. (8) and (9), the quilts (5), consequently (6). Detach the rods (17) and (10) of the back rests upholstery on the corresponding quilts and remove the upholstery (8) and (9) from the back rests quilts. REMOUNTING SEAT UPHOLSTERY DISMOUNTING 1 2 10 11 8 5 6 4 12 13 7 3 14 9 |
