44 REAR UPPER STRUCTURE REAR PANEL 44 - 3 DISMOUNTING Dismount the elements that are in contact with the rear panel. Detach the welding points of the rear panel (1) which are in connection with: - side panel edge in the area (2); area (3); - side panel in the area (4); Straighten the areas resulted from dismounting. Grind the areas resulted from dismounting. REMOUNTING Position and center the new element. panel. Weld the rear panel (1) following the welding outlines (2), (3) and (4)…; Protect the welding with a corrosion preventive product. Mount in the reverse order the elements that are in connection with the rear panel. 2 5 4 3 |
