COOLING - EXHAUST - FUEL TANK
19 - 17
( dismounting the tank from the vehicle not required )
D
ISMO UNTING
Unscrew the fixing screws of the fuel tank visiting cap.
Disconnect the rear wiring from the tank cap.
Dismount the fixing rings of the hoses and disconnect the hoses from the tank cap.
Dismount by turning counter clockwisedirection,the blocking ring of the tank cap.
Lift a little bet the tank cap,to enable unlocking the fixing clamp of the pump support in the
protector vessel; unlock the clamp and take out from the tank its cap together with support with
the electric pump and the fuel level transmitter.
Disconnect the feeding wiring from pump and fuel level transmitter.
Dismount the fixing ring of the hose going to the pump.
Unscrew the fixing screws of upper and lower rings of the fuel pump.
Take out the pump from the collars with gaskets.
R
EMOUNTING
Perform in reverse order the dismounting operations.
ATTENTION:
When mounting,good fixing rings are to be used and these will be well tightened.
The feeding wiring terminals of the pump and of the fuel level transmitter shall be well
fixed, to enable perfect electric contacts. The maximum applied force on connectors
terminals on axial direction of the pump shall not exceed 80 N.
ELECTRIC FUEL PUMP
