Peugeot Expert VU (2016 year). Manual

335

Technical data

Expert_en_Chap09_caracteristiques-techniques_ed01-2016

EuRo 6 Diesel engines

* Increased payload.

Engine

code

Gearbox

Engine oil capacity

with filter replacement

(litres)

Length

Unbraked trailer

weight (kg)

8-9 seats

Trailer nose weight

(kg)

8-9 seats

1.6 litre

BlueHDi 95

BHV

(DV6FDu)

Manual

(5-speed)

5.6

L1, L2, L3

750

L2*, L3*

1.6 litre

BlueHDi 95

S&S

BHS

(DV6FDu)

Etg6

electronic
(6-speed)

5.6

L1, L2, L3

L2*, L3*

1.6 litre

BlueHDi 115

S&S

BHX

(DV6FCu)

Manual

(6-speed)

5.6

L1, L2, L3

L2*, L3*

336

Technical data

Expert_en_Chap09_caracteristiques-techniques_ed01-2016

* Increased payload.

Engine

code

Gearbox

Engine oil capacity

with filter replacement

(litres)

Length

Unbraked trailer

weight (kg)

8-9 seats

Trailer nose weight

(kg)

8-9 seats

2 litre BlueHDi

150 S&S

AHX

(DW10FD)

Manual

(6-speed)

6.1

L1, L2, L3

750

L2*, L3*

100

2 litre BlueHDi

180 S&S

AHH

(DW10FC)

EAt6

automatic
(6-speed)

5.1

L1, L2, L3

L2*, L3*

337

Technical data

Expert_en_Chap09_caracteristiques-techniques_ed01-2016

Identification markings

Various visible markings for the identification of your vehicle.

A. Vehicle Identification Number (VIN)

under the bonnet.

this number is engraved on the chassis
near the right hand front wheel arch.

the tyre pressures must be checked
when the tyres are cold, at least once
a month.

If the tyre pressures are too low, this
increases fuel consumption.

B. Vehicle Identification Number (VIN) on

the windscreen lower cross member.

this number is indicated on a self-
adhesive label which is visible through the
windscreen.

C. Manufacturer's label.

this self-destroying label on the middle
door pillar, right or left hand side, contains
the following information:
- the manufacturer's name,
- the European whole vehicle type

approval number,

- the vehicle identification number (VIN),
- the maximum authorised weight (gross

vehicle weight),

- the maximum authorised weight with

trailer (gross train weight),

- the maximum front axle weight,
- the maximum rear axle weight.

D. Tyre/paint label.

this label on the middle door pillar, driver's
side, contains the following information:
- the tyre inflation pressures, laden and

unladen,

- the tyre sizes (including the tyre load

index and speed rating),

- the inflation pressure for the spare

wheel,

- the paint colour code.

338

Audio and Telematics

Emergency or assistance call

If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency call is made automatically.

PEUGEOT Connect SOS

In an emergency, press this
button for more than 2 seconds.
Flashing of the green LED and
a voice message confirm that
the call has been made to the
"PEugEot Connect SoS" call
centre*.

Pressing this button again immediately cancels
the request.
the green LED goes off.
Pressing this button for more than 8 seconds
cancels the request at any time.

the green LED remains on (without flashing)
when communication is established.
It goes off at the end of the call.

"PEugEot Connect SoS" immediately locates
your vehicle, starts communication with you in
your language**, and where necessary sends
the appropriate public emergency services**. In
countries where the service is not available, or
when the locating service has been expressly
declined, the call is sent directly to the
emergency services (112) without the vehicle
location .

** Depending on the geographical cover of

"PEugEot Connect SoS", "PEugEot
Connect Assistance" and the official national
language selected by the owner of the vehicle.
the list of countries covered and PEugEot
CoNNECt services is available from dealers
or at www.PEugEot.co.uk.

* Subject to the general conditions for the

service available from dealers and to
technological and technical limitations.

If you benefit from the PEugEot
Connect Packs offer with the SoS and
assistance pack included, there are
additional services available to you in
your MyPEugEot personal space, via
the Internet website for your country.

339

Audio and Telematics

PEUGEOT Connect Assistance

If you purchased your vehicle outside
the PEugEot dealer network, we
invite you to have a dealer check the
configuration of these services and, if
desired, modified to suit your wishes.
In a multi-lingual country, configuration
is possible in the official national
language of your choice.

For technical reasons and in particular
to improve the quality of "PEugEot
CoNNECt services" services to
customers, the manufacturer reserves
the right to carry out updates to the
vehicle's on-board telematic system.

A fault with the system does not
prevent the vehicle being driven.

Press this button for more than
2 seconds to request assistance
if the vehicle breaks down.
A voice message confirms that
the call has been made**.

Pressing this button again immediately cancels
the request.
the cancellation is confirmed by a voice
message.

the orange LED is on continuously: the backup
battery must be replaced.
In either case, the emergency and assistance
calls may not function.
Contact a qualified repairer as soon as
possible.

Operation of the system

When the ignition is switched
on, the green LED comes on for
3 seconds indicating that the
system is operating correctly.

If the orange LED flashes then
goes off: there is a system fault.

** Depending on the geographical cover of

Geo-location

You can deactivate geo-location by
simultaneously pressing the "PEugEot
Connect SoS" and "PEugEot Connect
Assistance" buttons, followed by a press on
"PEugEot Connect Assistance" to confirm.

to reactivate geo-location, simultaneously
press the "PEugEot Connect SoS" and
"PEugEot Connect Assistance" buttons
again, followed by a press on "PEugEot
Connect Assistance" to confirm.

341

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

PEugEot Connect Nav

GPS satellite navigation - Connectivity - Multimedia audio - Bluetooth

telephone

Contents

First steps

342

Steering mounted controls

344

Menus 345
Voice commands

346

Navigation 352
Connected navigation

368

Connectivity 378
Radio Media

388

telephone 400
Settings 412
Frequently asked questions

422

the system is protected in such a way that it will only operate in
your vehicle.

the link below gives access to oSS (open Source Software)
codes for the system.
http://www.psa-peugeot-citroen.com/oss

As a safety measure and because it requires sustained attention
by the driver, the pairing of a Bluetooth mobile telephone with
the Bluetooth hands-free system of your audio system must be
done with the vehicle stationary and the ignition on.
the display of the energy economy mode message signals that
a change to standby is imminent. For more information on the
Energy economy mode refer to the corresponding section.

342

FM/87.5 MHz
87.5MHz

12:13

23 °C

87.5 MHz

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns the
system on.

Volume.

use the buttons either side of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen. All of the touch
areas of the screen are white.
Each menu is displayed in one or two pages
(primary page and secondary page).

Secondary page

Primary page

the touch screen is of the "capacitive"
type.
to clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with
no additional product.
Do not use sharp objects on the
screen.
Do not touch the screen with wet
hands.

343

12:13

23 °C

531 kHz

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

Select the audio source (depending on
version):
-

FM / DAB* / AM* stations.

Smartphone via MirrorLink

or CarPlay

uSB memory stick.

Media player connected to the auxiliary
socket (jack, cable not supplied).

telephone connected by Bluetooth* and
using Bluetooth* audio streaming.

* Depending on equipment.

Short-cuts: using the virtual buttons in the
upper band of touch screen, it is possible to
go directly to the selection of audio source,
the list of stations (or titles, depending on
the source), message notifications, emails,
mapping updates and, depending on services,
navigation notifications.

In very hot conditions, the volume may
be limited to protect the system. It may
go into standby (screen and sound off)
for at least 5 minutes.
the return to normal takes place when
the temperature in the passenger
compartment drops.

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with
the possibility of entering a multitude
of settings (radio presets, audio
settings, navigation history, contact
favourites, ...); these settings are taken
into account automatically.

344

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

Steering mounted controls

Media (short press): change the
multimedia source.
Telephone (short press): call.
Call in progress (short press):
access to telephone menu.
Telephone (long press): reject an
incoming call, end call, access to
telephone menu.

Decrease volume.

Voice commands:
Short press, system voice
commands.
Long press, smartphone voice
commands via the system.

Mute / Restore the sound.

Radio (rotate): automatic search for
the previous / next station.
Media (rotate): previous / next track,
move in a list.
Short press: Confirm a selection.
other than selection, access to
presets.

Radio: display the list of stations.
Media: display the list of tracks.
Radio, press and hold: update the
list of stations received.

Increase volume.

345

12:13

23 °C

12:13

23 °C

531 kHz

FM/87.5 MHz
87.5MHz

12:13

23 °C

87.5 MHz

12:13

23 °C

531 kHz

12:13

23 °C

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

Menus

Settings

Radio Media

Connected navigation

Driving

Connectivity

Telephone

Enter settings for a personal profile and/or
adjust the settings for sound (balance,
ambience, ...), and the display (language, units,
date, time, ...).

Select an audio source, a radio station, display
photographs.

Enter navigation settings and choose a
destination.
use services available in real time, depending
on equipment.

Activate, deactivate, adjust the settings for
certain vehicle functions.

operate certain applications on a smartphone
connected via MirrorLink

or CarPlay

Check the state of Bluetooth and Wi-Fi
connections.

Connect a telephone by Bluetooth

, read

messages and emails and send quick
messages.

346

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

Voice commands

First steps

Steering mounted controls

Information - Using the system

Press the Push to talk
button and tell me what you'd
like after the tone. Remember
you can interrupt me at any

time by pressing this button. If you
press it again while I'm waiting for you
to speak, it'll end the conversation. If
you need to start over, say "cancel".
If you want to undo something, say
"undo". And to get information and tips
at any time, just say "help". If you ask
to me do something and there's some
information missing that I need, I'll
give you some examples or take you
through it step by step. there's more
information available in "novice" mode.
You can set the dialogue mode to
"expert" when you feel comfortable.

to ensure that voice commands are
always recognised by the system,
please observe the following
recommendations:
-

speak in a normal tone without
breaking up words or raising your
voice.

always wait for the "beep" (audible
signal) before speaking.

for best operation, it is
recommended that the windows
and opening roof (if fitted) be
closed to avoid interference from
extraneous noises.

before making a voice command,
ask other passengers to not speak.

the voice commands, with a choice
of 12 languages (English, French,
Italian, Spanish, german, Dutch,
Portuguese, Polish, turkish, Russian,
Arabic, Brazilian), are made using the
language previously chosen and set in
the system.

the voice commands in Arabic for:
"Navigate to address" and "Display PoI
in the city", are not available.

Example of a "voice command" for
navigation:
"Navigate to address 11 Regent
Street, London".

Example of a "voice command" for
the radio and media:
"Play artist Madonna".

Example of a "voice command" for
the telephone:
"Call David Miller".

Pressing this button activates the
voice commands function.

347

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

Global voice commands

these commands can be made from any screen page after pressing the voice command or telephone button located on the steering wheel, as
long as there is no telephone call in progress.

"Voice command"

Help message

Help

there are lots of topics I can help you with.
You can say: "help with phone", "help with navigation", "help with media" or "help with radio".
For an overview on how to use voice controls, you can say "help with voice controls".

Voice command help

Navigation help

Radio help

Media help

Telephone help

Set dialogue mode as <...>

Select "beginner" or "expert" mode.

Select profile <...>

Select profile 1, 2 or 3.

Yes

Say "yes" if I got that right. otherwise, say "no" and we'll start that again.

348

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

"Navigation" voice commands

these commands can be issued from any screen page after pressing the voice command or telephone button on the steering wheel, as long as
there is no telephone call in progress.

Depending on the country, give the destination instructions (address) in the language used by the system.

"Voice command"

Help message

Navigate home

to start guidance or add a stopover, say "navigate to" and then the address or contact name.
For example, "navigate to address 11 Regent Street, London", or "navigate to contact,
John Miller".
You can specify if it's a preferred or recent destination. For example, "navigate to preferred
address, tennis club", "navigate to recent destination, 11 Regent Street, London".
otherwise, just say, "navigate home". to see points of interest on a map, you can say
things like "show hotels in Banbury" or "show nearby petrol station".
For more information you can ask for "help with route guidance".

Navigate to work

Navigate to preferred address <...>

Navigate to contact <...>

Navigate to address <...>

Show nearby POI <...>

Remaining distance

to get information about your current route, you can say "tell me the remaining time",
"distance" or "arrival time".
try saying "help with navigation" to learn more commands.

Remaining time

Arrival time

Stop route guidance

349

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

"Radio Media" voice commands

these commands can be issued from any screen page after pressing the voice command or telephone button on the steering wheel, as long as
there is no telephone call in progress.

"Voice command"

Help message

Tune to channel <...>

You can pick a radio station by saying "tune to" and the station name or frequency.
For example "tune to channel talksport" or "tune to 98.5 FM". to listen to a preset radio
station, say "tune to preset number". For example "tune to preset number five".

What's playing

to display the details of the current "track", "artist" and "album", you can say "What's
playing"

Play song <...>

use the command "play" to select the type of music you'd like to hear. You can pick by
"song", "artist", or "album". Just say something like "play artist, Madonna", "play song,
Hey Jude", or "play album, thriller".

Play artist <...>

Play album <...>

Media voice commands are available only for a uSB connection.

350

Audio and Telematics

Expert_en_Chap10b_NAC-1_ed01-2016

"Voice command"

Help message

Call contact <...>*

to make a phone call, say "call" followed by the contact name, for example: "Call
David Miller".
You can also include the phone type, for example: "Call David Miller at home".
to make a call by number, say "dial" followed by the phone number, for example,
"Dial 107776 835 417".
You can check your voicemail by saying "call voicemail".
to send a text, say "send quick message to", followed by the contact, and then the name
of the quick message you'd like to send.
For example, "send quick message to David Miller, I'll be late".
to display the list of calls, say "display calls".
For more information on SMS, you can say "help with texting".

Dial <...>*

Display contacts*

Display calls*

Call (message box | voicemail)*

* this function is available only if the telephone connected to the system supports downloading of contacts and recent calls and if the download has

been done.

"Telephone" voice commands

If a telephone is connected to the system, these voice commands can be issued from any main screen page after pressing the telephone
button on the steering wheel, as long as there is no telephone call in progress.
If there is no telephone connected by Bluetooth, a voice message announces: "Please first connect a telephone" and the voice session will be
closed.

Peugeot Expert VU (2016 year). Manual - part 22
