Peugeot 3008 (2017 year). Manual

137

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

on the steering mounted button.

Calling a contact

Setting the ringtone

Press

Telephone to display the

primary page.

Or make a long press

on the steering mounted

PHONE

button.

Press "

Contacts ".

Select the desired contact from the list offered.

Press "

Call ".

Calling a recently used number

Press

Telephone to display the

primary page.

Make a long press

Press "

Recent calls ".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

Press

Telephone to display the

primary page.

Press "

Ring volume " to display the

volume bar.

Press the arrows or move the cursor
to set the ring volume.

Press the "

OPTIONS " button to go to

the secondary page.

139

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Brightness

Ambience

Move the cursor to adjust the brightness of the
screen and/or of the instrument panel.

Settings

Profiles

Profile 1

Select a profile.

Profile 2

Profile 3

Common profile

Name:

Profile name

modification

Configure the profiles.

Reset the profile

Yes / No

Profile activated

Activate/deactivate the profile selected.

Save the settings.

Settings

Dark

Function which switches off the lit display.
Pressing the screen reactivates it.

141

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Settings

Configuration

System configuration

Configure certain system parameters.

Ambience

Select an ambience for the screen integrated in
the system.

Language

Select the display language for the the screen
and/or the instrument panel.

Screen configuration

Set the configuration of the screen and/or the
instrument panel.

Customization

Configure the instrument panel for a personalised
display.

Date and time

Set the date and time and select the display
format.

143

8
9

10
11

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Settings

Configuration

System

configuration

Units

Distance and fuel

consumption

Configure the display units for the distance,
consumption and temperature.

Temperatures

Factory settings

Reset

Restore the original settings.

System info

View

Consult the version of the different modules
installed in the system.

Save the parameters.

Settings

Configuration

Ambience

Select an ambience for the screen integrated in
the system.

Confirm the selection and start the change of
ambience.

Settings

Configuration

Language

All

Select the display language for the screen and/or
the instrument panel.

Europe

Asia

America

Save the parameter.

145

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 2

Level 3

Comments

Settings

Configuration

Screen

configuration

Brightness

Select the display brightness level.

Animation

Automatic scrolling

Activate or deactivate the parameters.

Animated transitions

Save the parameters.

Settings

Configuration

Temperature conditioning

Customization

Choose and select the display information
required.

Confirm

Confirm the selections.

Settings

Configuration

Date and time

Time

Set the time.

Time Zone

Set the time zone.

Select the display format.

12h

GPS Synchronisation

Activate or deactivate the synchronisation with the
satellites.
Save the settings.

Date

Set the date and select the display format.

Setting the date

Save the settings.

146

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Profile settings

Adjust the brightness

Press "

OK " to save.

Select "

Profile 1 " or " Profile 2 " or

Profile 3 " or " Common profile ".

Press "

Profiles ".

Press this button to enter a name for
the profile using the virtual keypad

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the

vehicle stationary .

vehicle stationary

Press this button to activate the
profile.

Press this button to initialise the
profile selected.

Press

Settings to display the primary

page.

Move the cursor to adjust the brightness
of the screen and/or of the instrument
panel (according to version).

Press

Brightness .

Press in the grey zone to confirm.

Press the back arrow to confirm.

Press the back arrow again to
confirm.

147

5
6

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press

Settings to display the primary

page.

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

System configuration ".

Press "

Screen configuration ".

Press "

Units " to change the units

for distance, fuel consumption and
temperature.

Select "

Language " to change the

language.

Activate or deactivate: "

Automatic

scrolling ".

Select "

Animated transitions ".

Move the cursor to set the brightness
of the screen and/or instrument panel
(according to version).

Press "

Factory settings " to return to

the initial settings.

Press "

System info " to display the

versions of the different modules
installed in the system.

Modifying system settings

Returning the system to factory settings
activates the English language by
default (according to version).

Press "

Animation ".

Press "

Brightness ".

Select the language

Press the back arrow to confirm.

148

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Press

Settings to display the primary

page.

Select "

Date ".

Select "

Time ".

Press "

Date and time ".

Adjustment of the time and date is only
available if "GPS Synchronisation:" is
deactivated.
The change between winter and
summer time is done by changing the
time zone.

The system does not automatically
manage the change between winter
and summer time (depending on the
country of sale).

Setting the time

Press this button to define the date.

Press this button to adjust the time
using the virtual keypad.

Press the back arrow to save the
date.

Press this button to define the time
zone.

Select the display format of the date.

Select the display format for the
time (12h / 24h).

Activate or deactivate
synchronisation with satellites (UTC).

Press

Settings to display the primary

page.

Press "

Date and time ".

Setting the date

Press "

Configuration " to go to the

secondary page.

Press "

Configuration " to go to the

secondary page.

Press "

OK " to save the time.

Press the back arrow to save the
settings.

Press the back arrow again to
confirm.

149

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Radio

QUESTION

ANSWER

SOLUTION

The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5 Mhz is displayed...).

The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.

Activate the "RDS" function by means of the
upper band to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault with the audio system.

The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio
stations in the list of
stations received.

The station is not received or its name has changed in the list.

Press the round arrow on the "List" tab of the
"Radio" page.

Some radio stations send other information in place of their name
(the title of the song for example).
The system interprets this information as the name of the station.

The name of the radio
station changes.

Frequently asked questions

The following table groups together the answers to the most frequently asked questions concerning your audio system.

150

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Media

QUESTION

ANSWER

SOLUTION

Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes).

Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some characters in the
media information are not
displayed correctly while
playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming files
does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and
the track length are not
displayed on the screen
when streaming audio.

The Bluetooth profile does not allow the transfer of this information.

151

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

QUESTION

ANSWER

SOLUTION

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the
telephone may not be visible.

Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with the system.

You can check the compatibility of your telephone
at the Brand's website (services).

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.

The ambient noise level has an influence on the quality of telephone
communication.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).

Contacts are not shown in
alphabetical order.

Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order.

Modify the display setting in the telephone
directory.

Telephone

152

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

QUESTION

ANSWER

SOLUTION

In changing the setting
of treble and bass the
equalizer setting is
deselected.

The selection of an equalizer setting imposes the settings for treble
and bass and vice-versa.

Modify the treble and bass or equalizer settings to
obtain the desired musical ambience.

In changing the equalizer
setting, treble and bass
return to zero.

When changing the
balance settings, the
distribution setting is
deselected.

The selection of a distribution setting imposes the balance settings
and vice-versa.

Modify the balance or distribution settings to
obtain the desired musical ambience.

When changing a
distribution setting,
the balance setting is
deselected.

There is a difference in
sound quality between the
different audio sources.

For optimum sound quality, the audio settings can be adapted to
the different sound sources, which may result in audible differences
when changing source.

Check that the audio settings are adapted to the
sources listened to. Adjust the audio functions to
the middle position.

With the engine off, the
system switches off after a
few minutes of use.

When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode and
switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

Settings

Peugeot 3008 (2017 year). Manual - part 32
