Peugeot 407 (2010 year). Manual

ACCESS

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REINITIALISATION

      Switch off the ignition.
     Switch the ignition on again.
     Press the remote control locking but-

ton immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the ig-
nition lock. The remote control is
now working again.

If the remote control does not work
after the battery has been changed,
reinitialise the remote control.

ELECTRONIC ENGINE
IMMOBILISER

Electronic engine immobiliser
indicator lamp

It is accompanied by a message on
the multi-function screen.
Your vehicle will not start.
Consult a PEUGEOT dealer.

  This  locks  the  engine  control  sys-
tem as soon  as the ignition  has  been
switched  off  and  therefore  prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic chip
which has a special code. When the ig-
nition is switched on, the code must be
recognised for starting to be possible.

If the system does not function correct-
ly, the following indicator lamp comes on:

Remote control

The  high  frequency  remote  control  is
a  sensitive  system;  do  not  operate  it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons of
your  remote  control  out  of  range  and
out of sight of your vehicle. You run the
risk of stopping it from working and the
remote control would have to be reini-
tialised.
The  remote  control  does  not  operate
when  the  key  is  in  the  ignition,  even
when  the  ignition  is  switched  off,  ex-
cept for reinitialisation.

Locking the vehicle

Driving  with  the  doors  locked  may
make  access  to  the  passenger  com-
partment  by  the  emergency  services

more difﬁ cult in an emergency.
As  a  safety  precaution  (with  children
on  board),  remove  the  key  from  the
ignition  when  you  leave  the  vehicle,
even for a short time.

Lost keys

Visit a PEUGEOT dealer with
the vehicle's V5 registration

document and your personal identiﬁ -

cation documents.
The PEUGEOT dealer will be able to re-
trieve the key code and the transponder
code required to order a replacement key.

ACCESS

Anti-theft protection

Do not make any modiﬁ ca-

tions to the electronic engine
immobiliser system; this could
cause malfunctions.

CHILD LOCK

This prevents opening of both of the
rear doors from the inside.
With the ignition on, press the button.
A message appears on the multi-func-
tion display.
This system is independent and does
not, in any circumstances, take the
place of the central locking control.

Electric mode

When purchasing a second-
hand vehicle

Have  the  key  codes  memorised  by  a
PEUGEOT  dealer,  to  ensure  that  the
keys  in  your  possession  are  the  only
ones which can start the vehicle.

Do not throw the remote con-
trol batteries away, they contain
metals which are harmful to the
environment.
Take them to an approved col-
lection point.

Always remove the ignition
key when leaving the vehicle,
even for a short time.
It is advisable to check that

the  child  lock  is  active  each  time  the
ignition is switched on.
In  the  event  of  a  serious  impact,  the
electric child lock is deactivated auto-
matically to permit the exit of the rear
passengers.

ACCESS

Using the remote control

 Pressing button B locks the vehicle

(the direction indicators come on
for approximately two seconds).



A second press within ﬁ ve seconds

deadlocks the vehicle (the direction
indicators come on for approximately
two seconds).

LOCKING/UNLOCKING FROM
THE INSIDE

MANUAL LOCKING
(EMERGENCY MODE)

Automatic central locking of
the doors

The  doors  can  lock  automatically
while  driving  (speed  above  6  mph
[10 km/h]).
Press  and  hold  the  button  to  activate
or deactivate this function.

Key in ignition

A  buzzer  sounds  on  opening  the  dri-
ver's  door,  if  the  key  has  been  left  in
the ignition.

LOCATING YOUR VEHICLE

To locate your vehicle, if you have
locked or deadlocked it, in a car park:
 press button B on the remote con-

trol, the courtesy lamps come on

and the direction indicators ﬂ ash

for a few seconds.

  Note:   driving  with  the  doors
locked  may  make  access  to
the passenger compartment by
the  emergency  services  more

difﬁ cult in an emergency.

If  the  vehicle  is  deadlocked,
the button is not active. In this
case,  use  the  key  or  the  re-
mote control to unlock.

 Press the button.
This allows the doors and the boot to
be locked or unlocked.

Driver's door

Insert the key in the lock to lock or unlock
the door.
Passenger doors

To  lock,  insert  the  key  in  the  control
located  on  the  edge  of  the  door  then
turn to the right.

ACCESS

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REINITIALISATION

      Switch off the ignition.
     Switch the ignition on again.
     Press the remote control locking but-

ton immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the ig-
nition lock. The remote control is
now working again.

If the remote control does not work
after the battery has been changed,
reinitialise the remote control.

ELECTRONIC ENGINE
IMMOBILISER

Electronic engine immobiliser
indicator lamp

It is accompanied by a message on
the multi-function screen.
Your vehicle will not start.
Consult a PEUGEOT dealer.

If the system does not function correct-
ly, the following indicator lamp comes on:

Remote control

Locking the vehicle

Driving  with  the  doors  locked  may
make  access  to  the  passenger  com-
partment  by  the  emergency  services

more difﬁ cult in an emergency.
As  a  safety  precaution  (with  children
on  board),  remove  the  key  from  the
ignition  when  you  leave  the  vehicle,
even for a short time.

Lost keys

Visit a PEUGEOT dealer with
the vehicle's V5 registration

document and your personal identiﬁ -

cation documents.
The PEUGEOT dealer will be able to re-
trieve the key code and the transponder
code required to order a replacement key.

ACCESS

CHANGING THE REMOTE
CONTROL BATTERY

Battery ref.: CR1620/3 volts.
To change the battery, unclip the casing
using a coin at the notch.

REINITIALISATION

      Switch off the ignition.
     Switch the ignition on again.
     Press the remote control locking but-

ton immediately for a few seconds.

 Switch off the ignition and remove

the remote control key from the ig-
nition lock. The remote control is
now working again.

If the remote control does not work
after the battery has been changed,
reinitialise the remote control.

ELECTRONIC ENGINE
IMMOBILISER

Electronic engine immobiliser
indicator lamp

It is accompanied by a message on
the multi-function screen.
Your vehicle will not start.
Consult a PEUGEOT dealer.

If the system does not function correct-
ly, the following indicator lamp comes on:

Remote control

Locking the vehicle

Driving  with  the  doors  locked  may
make  access  to  the  passenger  com-
partment  by  the  emergency  services

more difﬁ cult in an emergency.
As  a  safety  precaution  (with  children
on  board),  remove  the  key  from  the
ignition  when  you  leave  the  vehicle,
even for a short time.

Lost keys

Visit a PEUGEOT dealer with
the vehicle's V5 registration

document and your personal identiﬁ -

cation documents.
The PEUGEOT dealer will be able to re-
trieve the key code and the transponder
code required to order a replacement key.

ACCESS

Anti-theft protection

Do not make any modiﬁ ca-

tions to the electronic engine
immobiliser system; this could
cause malfunctions.

CHILD LOCK

Electric mode

When purchasing a second-
hand vehicle

Have  the  key  codes  memorised  by  a
PEUGEOT  dealer,  to  ensure  that  the
keys  in  your  possession  are  the  only
ones which can start the vehicle.

Do not throw the remote con-
trol batteries away, they contain
metals which are harmful to the
environment.
Take them to an approved col-
lection point.

Always remove the ignition
key when leaving the vehicle,
even for a short time.
It is advisable to check that

ACCESS

Anti-theft protection

Do not make any modiﬁ ca-

tions to the electronic engine
immobiliser system; this could
cause malfunctions.

CHILD LOCK

Electric mode

When purchasing a second-
hand vehicle

Have  the  key  codes  memorised  by  a
PEUGEOT  dealer,  to  ensure  that  the
keys  in  your  possession  are  the  only
ones which can start the vehicle.

Do not throw the remote con-
trol batteries away, they contain
metals which are harmful to the
environment.
Take them to an approved col-
lection point.

Always remove the ignition
key when leaving the vehicle,
even for a short time.
It is advisable to check that

ACCESS

ALARM

For all work on the alarm system, contact
a PEUGEOT dealer.

Exterior perimeter

The system checks for opening of the
vehicle.
The alarm is triggered if anyone tries
to open a door, the boot, the bonnet...

Interior volumetric

The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks
a window, enters the passenger com-
partment or moves inside the vehicle.

Self-protection function

The system checks for the
putting out of service of its
components.

The alarm is triggered if the battery, the
central control or the wires of the siren
are put out of service or damaged.

Locking the vehicle with full
alarm system

Activation

 Switch off the ignition and get out

of the vehicle.

 Press the locking button on the re-

mote control.

The monitoring system is active: the

indicator lamp on the button ﬂ ashes

once per second.
After the locking button on the remote
control is pressed, the exterior perime-
ter monitoring is activated after a delay
of 5 seconds and the interior volumetric
after a delay of 45 seconds.
If  an  opening  (door,  boot...)  is  not
closed  fully,  the  vehicle  is  not  locked
but  the  exterior  perimeter  monitor-
ing  will  be  activated  after  a  delay  of
45  seconds  at  the  same  time  as  the
interior volumetric monitoring.

System which protects and provides a
deterrent against theft and break-ins.
It provides the following types of moni-
toring.

Deactivation

 Press the unlocking button on the

remote control.

The alarm system is deactivated: the in-
dicator lamp on the button switches off.

Locking the vehicle with
exterior perimeter monitoring
only

Deactivate the interior volumetric pro-
tection to avoid unwanted triggering of
the alarm in certain cases such as:
-

leaving a pet in the vehicle,

leaving a window partially open,

washing your vehicle,

changing a wheel,

having your vehicle towed,

transport by sea.

Deactivation of the interior
volumetric monitoring

 Switch off the ignition.
 Within ten seconds, press the but-

ton until the indicator lamp is lit
continuously.

 Get out of the vehicle.
 Press the locking button on the re-

mote control immediately.

The exterior perimeter monitoring alone
is activated: the indicator lamp on the

button ﬂ ashes once per second.
To be effective, this deactivation must
be carried out each time the ignition is
switched off.

ACCESS

Reactivation of the interior
volumetric monitoring

 Press the unlocking button on the

remote control to deactivate the
exterior perimeter monitoring.

 Press the locking button on the

remote control to activate all the
monitoring functions.

The indicator lamp on the button again

ﬂ ashes once per second.

Triggering of the alarm

This is indicated by sounding of the

siren and ﬂ ashing of the direction indi-

cators for thirty seconds.
The monitoring functions remain ac-
tive until the alarm has been triggered
eleven times in succession.
When the vehicle is unlocked using

the remote control, rapid ﬂ ashing of

the indicator lamp on the button in-
forms you that the alarm was triggered
during your absence. When the igni-

tion is switched on, this ﬂ ashing stops

immediately.

Failure of the remote control

To deactivate the monitoring functions:

 Unlock the vehicle using the key in

the driver's door lock.

 Open the door; the alarm is trig-

gered.

 Switch on the ignition; the alarm

stops. The indicator lamp on the
button switches off.

Locking the vehicle without
activating the alarm

 Lock or deadlock the vehicle using

the key in the driver's door lock.

Malfunction

When the ignition is switched on, ﬁ xed

lighting  of  the  indicator  lamp  on  the
button  indicates  a  malfunction  of  the
system.
Have it checked by a PEUGEOT dealer.

* According to country.

Automatic activation *

2 minutes after the last door or the
boot is closed, the system is activated
automatically.
 To avoid triggering the alarm on

entering the vehicle, ﬁ rst press the

unlocking button on the remote
control.

ACCESS

ELECTRIC WINDOWS

  Automatic operation:
To open or close the window, press or
pull switch fully: the window opens or
closes  completely  when  the  switch  is
released.  Pressing  the  switch  again
stops the movement of the window.
The  electric  window  switches  remain
operational for approximately one min-
ute  after  the  key  has  been  removed
from the ignition.
Once this time has elapsed, the electric
windows will not operate. To reactivate
them, switch the ignition on again.

Always  remove  the  key  from
the  ignition  when  leaving  the
vehicle, even for a short time.
In the  event  of contact during

operation of the windows, you must re-
verse the movement of the window. To
do this, press the switch concerned.
When the driver operates the passen-
ger electric window switches, he must
ensure  that  no  one  is  preventing  cor-
rect closing of the windows.
The  driver  must  ensure  that  the  pas-
sengers use the electric windows cor-
rectly.
Be  aware  of  children  when  operating
the windows.

REINITIALISATION OF
THE ELECTRIC WINDOWS

Following reconnection of the battery,
the safety anti-pinch function must be re-
initialised: the safety anti-pinch function
is not active during these operations.
-

lower the window completely, then
raise it, it will rise in steps of a few
centimetres each time the switch is
pressed. Repeat the operation un-
til the window closes completely,

continue to press the switch for at
least one second after reaching
this position, window closed.

Safety anti-pinch

When the window rises and meets an
obstacle, it stops and immediately par-
tially lowers again.
In  the  event  of  unwanted  opening
of  the  window  on  closing,  press  the
switch  until  the  window  opens  com-
pletely, then pull the switch immediate-
ly until the window closes. Continue to
hold the switch for approximately one
second after the window has closed.
The  safety  anti-pinch  function  is  not
active during this operation.

Deactivating the rear window
controls

For  the  safety  of  your  children,  press
switch  5  to prevent operation of the rear
windows irrespective of their position.
When  the  button  is  pressed  down,  the
switches are deactivated. When the but-
ton is raised, the switches are active.

  Manual operation:
To  open  or  close  the  window,  press
or  pull  the  switch  gently.  The  win-
dow  stops  as  soon  as  the  switch  is
released.

1. Driver's electric window switch.
2. Passenger's electric window

switch.

3. Rear right electric window

switch.

4. Rear left electric window

switch.

5. Deactivating the rear electric

window switches (child safety).

ACCESS

BOOT (SALOON)

TAILGATE AND REAR SCREEN
(407SW)

Partial opening of the rear screen

Opening the tailgate and rear
screen

  The tailgate and rear screen cannot
be opened at the same time.
With  the  rear  screen  closed,  to  open
the   tailgate ,  operate  the  handle   A ,
then lift the tailgate.
With  the  tailgate  closed,  to  open  the
rear  screen ,  operate  the  handle   B ,
then lift the rear screen.
The boot lighting is controlled by open-
ing the tailgate or the rear screen.

If the permanent locking of the
boot is activated, opening is
only possible by pressing the
remote control button.

Notes: the tailgate and rear
screen lock automatically when
driving at 6 mph (10 km/h) and
unlock when one of the doors
is opened.

When  the  rear  wiper  is  in  a  wiping
position,  the  rear  screen  cannot  be
opened until the end of the cycle.
Close the rear screen using the wiper
arm  or  by  pressing  the  centre  of  the
glass.

To open the boot, press the push button
and raise the tailgate.

The locking or unlocking of the tailgate
and rear screen is simultaneous with
that of the doors.

With  the  tailgate  closed,  to  partially
open the  rear screen , press and hold
the unlocking button  C  on the remote
control.

ACCESS

BOOT (SALOON)

TAILGATE AND REAR SCREEN
(407SW)

Partial opening of the rear screen

Opening the tailgate and rear
screen

If the permanent locking of the
boot is activated, opening is
only possible by pressing the
remote control button.

Notes: the tailgate and rear
screen lock automatically when
driving at 6 mph (10 km/h) and
unlock when one of the doors
is opened.

To open the boot, press the push button
and raise the tailgate.

The locking or unlocking of the tailgate
and rear screen is simultaneous with
that of the doors.

With  the  tailgate  closed,  to  partially
open the  rear screen , press and hold
the unlocking button  C  on the remote
control.

ACCESS

"Rear screen open" warning

  When  the  engine  is  running ,  if  the
rear screen is not fully closed, you are
warned  by  a  message  on  the  multi-
function screen.
  When the vehicle is moving  (speed
greater  than  6  mph  (10  km/h)),  if  the
rear screen is not fully closed, you are
warned  by  an  audible  signal,  a  mes-
sage  on  the  multifunction  screen  and
lighting of the service warning lamp.

Tailgate release

This enables the tailgate to be un-
locked in the event of a central locking
fault.
-

Fold back the rear seats to gain
access to the lock from inside the
boot.

Insert a small screwdriver into hole A
of the lock to unlock the tailgate.

ACCESS

Notes:

After reconnecting the battery, you
must reinitialise the safety anti-pinch:
-

place the control in the maximum
partial opening position (3rd notch
to the right),

wait until the roof is in the maxi-
mum partially open position,

press the control for at least one
second.

In  the  event  of  unwanted  opening  of
the roof on closing (for example, in the
presence  of  ice),  and  immediately  af-
ter the roof stops:
   -

move the control to the "O" position
and press the control immediately,

continue to press the control until
the roof is fully closed.

SUNROOF (SALOON)

Always  remove  the  key  from
the  ignition  when  leaving  the
vehicle, even for a short time.
In the  event  of contact during

operation of the roof, you must reverse
the  movement  of  the  roof. To  do  this,
press the switch concerned.
When  the  driver  operates  the  roof
switch,  they  must  ensure  that  no  one
is  preventing  correct  closing  of  the
roof.
The  driver  must  ensure  that  passen-
gers use the sunroof correctly.
Be  aware  of  children  when  operating
the roof.

To partially open the roof: Turn the
switch to the right (three possible
settings).

To open the roof completely: Turn
the switch to the left (six possible
settings).

To close it completely: Turn the
switch back to position "O".

Safety  anti-pinch:  When  the  sun-
roof  is  closing  and  meets  an  ob-
stacle, it stops then partially opens
again.

The sunroof blind is manual.

ACCESS

Safety anti-pinch

If  the  blind  encounters  an  obstacle
during  closing,  it  stops  and  partially
opens again.
You  must  reinitialise  the  safety  anti-

pinch within a maximum of ﬁ ve sec-

onds after the blind has stopped:
-

press part A of the control until the
blind is completely closed (closing
in stages of a few centimetres).

PANORAMIC SUNROOF (407SW)

  In  the  event  of  contact  du-
ring operation of the blind, you
must  reverse  its  movement.
To  do  this,  press  the  control
concerned.

When  the  driver  operates  the  blind-
control, they must ensure that no one
is  preventing  the  blind  from  closing
correctly.
The  driver  must  ensure  that  the  pas-
sengers use the blind correctly.
Pay attention to children during opera-
tion of the blind.

  Notes:
Following reconnection of the battery,
in  the  event  of  a  blind  malfunction
while it is moving or immediately after
it  has  stopped,  you  must  reinitialise
the safety anti-pinch:
   -

place the control in the fully open
position (position "0"),

wait until the blind is in the fully
open position,

press section A of the control for at
least three seconds.

In  the  event  of  unwanted  opening  of
the  blind  on  closing,  and  immediately
after the blind has stopped:
   -

move the control to the fully closed
position (9th setting to the left) then
press part A of the control straight
away,

continue to press the control until
the blind is fully closed.

The safety anti-pinch function is not
active during these operations.

Your vehicle is ﬁ tted with a tinted glass

panoramic  sunroof  which  increases
the  light  and  visibility  in  the  passen-
ger compartment. Its electric blind im-
proves temperature conditions.
  The  blind   is  controlled  electrically  by
a dial with nine opening positions.
  To close:  turn the dial to the left (nine
possible settings).
  To  open:   return  the  dial  to  the  initial
position  "0" .

ACCESS

FUEL TANK

The capacity of the tank is approxi-
mately 67 litres.

When  the  low  fuel  level  is
reached,  this  warning  lamp
comes  on  in  the  instrument
panel, accompanied by an au-

dible signal and a message on the mul-

tifunction screen. When it ﬁ rst comes

on,   about  6  litres   of  fuel  remains  in
the tank.
If  you  run  completely  out  of  fuel
(Diesel),  refer  also  to  the  "Checks"
section.

A label ﬁ tted to the inside of the fuel

ﬁ ller ﬂ ap indicates which type of fuel

to use.
Additions of fuel must be of at least
5 litres to be taken into account by the
fuel gauge.

Opening the fuel ﬁ ller may produce the

noise of an inrush of air. This vacuum
is entirely normal and results from the
sealing of the fuel system.

Low fuel warning

To refuel in complete safety:
 you must switch off the engine,


open the fuel ﬁ ller ﬂ ap.

 turn the cap to the left.
 remove the cap and hang the end

on the hook located on the inside

of the ﬂ ap.



ﬁ ll the tank, but do not continue

after the third cut-off of the noz-
zle ; this may cause malfunctions.

After ﬁ lling the tank:


reﬁ t the cap,



close the ﬂ ap.

Operating fault

A fuel gauge fault is indicated by the
fuel guage needle returning to zero.
Have it checked by a PEUGEOT dealer.

Refuelling

Peugeot 407 (2010 year). Manual - part 5
