54 Seats, restraints X : no ISOFIX child restraint system approved for this weight class 1 : move seat forwards as far as necessary and adjust seat backrest as far as necessary to a vertical position to ensure that the belt runs forwards from the upper anchorage point 2 : move seat upwards as far as necessary and adjust seat backrest as far as necessary to a vertical position to ensure that the belt is tight on the buckle side 3 : move the respective front seat ahead of the child restraint system forwards as far as necessary 4 : adjust the respective backrest to the rearmost position 3 57, adjust the respective headrest as necessary or 5 : ISOFIX / Top-tether fastening points optional for the front passenger seat (not available for sport seats) ISOFIX size class and seat device A – ISO/F3 : forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg B – ISO/F2 : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg B1 – ISO/F2X : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg C – ISO/R3 : rear-facing child restraint system for children of maximum size in the weight class up to 18 kg D – ISO/R2 : rear-facing child restraint system for smaller children in the weight class up to 18 kg E – ISO/R1 : rear-facing child restraint system for young children in the weight class up to 13 kg |
