3C – 24 FRONT SUSPENSION INSTALLATION 3. Upper Ball Joint 2. Bolt, Nut and Washer Upper Ball Joint Bracket Nut Torque N·m (kg·m/lb·ft) 57 (5.8 / 42) 1. Nut and Cotter Pin Tighten the nut to the specified torque with just Upper Ball Joint Nut Torque N·m (kg·m/lb·ft) 98 (10.0 / 72) |
