2A – 50 STEERING LINKAGE 2. Bolt and Nut Remove stabilizer bar bolts and nuts and push the 3. Relay Lever and Bracket 4. Nut and Washer 5. Relay Lever Remove relay lever from the bracket. Remover: 5-8840-0015-0 (J-22912-01) 6. Bracket INSTALLATION 6. Bracket 5. Relay Lever 4. Nut and Washer Relay Lever Nut Torque N·m (kg·m/lb·ft) 118 (12.0 / 87) 3. Relay Lever and Bracket 2. Bolt and Nut Bracket Nut Torque N·m (kg·m/lb·ft) 44 (4.5 / 33) 1. Nut and Cotter Pin Tighten the nut to the specified torque, with just Relay Lever Nut Torque N·m (kg·m/lb·ft) 59 (6.0 / 43) |
