1B – 50 AIR CONDITIONING Removal Steps 1. Radiator grille Installation Steps To install, follow the removal steps in the REMOVAL Preparation: • Disconnect the battery ground cable • Discharge and recover refrigerant (Refer to 1. Radiator Grille 2. Air Cleaner 2a. Duct 2b. Battery and Reserver Tank 2c. Air Cleaner Cover 3. Clip and Clamp 4. Liquid Line (High-pressure pipe) 5. Suction Line (Low-pressure pipe) 6. Suction Line (Low-pressure hose) 7. Discharge Line (High-pressure hose) • Use a back-up wrench when disconnecting and • When removing the refrigerant line connecting INSTALLATION To install, follow the removal steps in the reverse order, 1. O-rings cannot be reused. Always replace new ones. connecting refrigerant lines. 3. Tighten the refrigerant line to the specified torque. (Refer to “SERVICE INFORMATION” for FIXING |
