8F–96 BODY STRUCTURE Windshield Parts Location 607RW006 Legend (1) Windshield Upper Moulding (6) Windshield Support (10) Windshield Removal 1. Disconnect the battery ground cable. D Refer to Wiper/Washer System section. 3. Remove front cowl cover. D Refer to Cowl Cover removal steps in this section. 4. Remove windshield side moulding. D Pull the moulding out from the windshield side 5. Remove windshield support. D Use a knife to cut through part of the adhesive D Secure one end of a piece of steel piano wire (1) (0.02 607RS002 |
