8D–298
WIRING SYSTEM
A/T Shift Lock
General Description
The circuit consists of stoplight switch or brake
switch and shift lock controller.
This system is designed not to allow shift lever to be
shifted from “P” position to any other position
without depressing brake pedal while starter switch
is turned on.
The solenoid pin at the lower portion of shift lever
retracts when brake pedal is not depressed, thus
causing shift lever cam to be locked by link lever.
