8D–114
WIRING SYSTEM
Parts Location (RHD)
Legend
(1) I-9
(2) C-66
(3) H-7, H-9
(4) C-16
(5) Glow Plug
×
4
(6) H-4, H-5
(7) E-37
(8) E-41
(9) C-60
(10) B-19
(11) Dropping Resistor
(12) C-59
(13) H-41, H-42
(14) H-3
(15) Relay and Fuse Box (X-17)
(16) Glow Relay-1 (C-51, C-52)
(17) Glow Relay-2 (C-53, C-54, C-55)
(18) C-39
(19) H-15, H-26
(20) Fuse Box
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
13
D08RWA27
