6J – 10 INDUCTION REMOVAL 1. Remove intercooler assembly. Refer to “Intercooler” in this manual. 2. Remove harness connector from motor and ITP sensor. 3. Loosen the two fixing nuts and remove the throttle valve assembly. Legend (1) Motor INSPECTION AND REPAIR 1. Check for catching somwhere on the throttle valve. the throttle valve, the throttle valve must replace. INSTALLATION 1. Put gasket on the intake manifold and install throttle valve. 2. Tighten nuts to the specified torque. Torque: 20 N·m (2.0 kg·m / 14.5 lb ft) 3. Reconnect harness connector to motor and ITPsensor. 4. Install intercooler assembly. 1 2 3 025RW032 INTAKE THROTTLE VALVE |
