6G – 4 ENGINE LUBRICATION
SUB OIL FILTER SPECIFICATIONS
Filtration Method
Full flow Paper
Filtration Area
0.12 m
2
Relief Valve opening
981 Kpa (10 kg/cm
2
/142 psi)
pressure
The sub oil filter requires no servicing until the
replacement interval is reached.
The element is designed to provide special filtering
efficiency until it becomes due for replacement.
It is recommended to check and replace the sub filter
when the engine is being overhauled or if it is broken
inside the engine.
442RW004
