6D – 4 ENGINE ELECTRICAL REMOVAL AND INSTALLATION OF THE REMOVAL 1. Negative cable INSTALLATION To install the battery, follow the removal procedure in 1. Make sure that the rod is hooked on the body side. 065RW029 MAIN DATA AND SPECIFICATIONS Model (JIS) 80D26R–MF 75D26R–MF Voltage (V) 12 12 Cold-Cranking Performance (Amp) 582 490 Reserve Capacity (Min) 133 123 Load Test (Amp) 300 300 Fast Charge Maximum Amperage (Amp) 6.5 6.5 |
