FUEL SYSTEM 6C – 17 • If it reads abnormal, loosen injection pump fixing nut and pump bracket adjust bolt, make adjustment by Pump fixing nut Adjust bolt • Remove the measuring device and tighten the CAUTION • When installing the distributor head plug, be sure to • Connect injection pipe. • Fit pipe clip where specified. INJECTION TIMING ADJUSTMENT • Set No.1 cylinder to top dead center. • Remove injection pump distributor head plug. • Cancel wax CSD with the handle of a driver. • Fit a dial gauge and set lift to 2 mm(0.0787 in). Measuring device: 5-8840-0145-0 • Set crankshaft damper pully top dead center mark • Set dial gauge in the “0” position. • Turn the crankshaft a little rightwise and leftwise • Turn the crankshaft in the normal direction and 0.5 (0.0197) mm(in) Standard 19 (1.9/13) N·m (Kg·m/lb·ft) 40 (4.1/30) N·m (Kg·m/lb·ft) 17 (1.7/12) N·m (Kg·m/lb·ft) |
