4JG2-NA/4JG2-TURBO ENGINE 6A2 – 13 26 (2.7/20) N·m(Kg·m/lb·ft) INSTALLATION 13. Turbocharger Assembly (4JG2-T Only) • Install the turbocharger asm with gasket in exh. 12. Exh. Adapter (4JG2-T Only) • Install exh. adapter and tighten bolts to the 11. Heat Protector (4JG2-T Only) 10. Exh. Pipe: Ft • Install exh. pipe and tighten bolts to the specified 9. Water Outlet Pipe: Turbo (4JG2-T Only) • Install water outlet pipe with new gasket to the 26 (2.7/20) N·m(Kg·m/lb·ft) 67 (6.8/49) N·m(Kg·m/lb·ft) 8(0.8/6) N·m(Kg·m/lb·ft) |
