8H–20 SECURITY AND LOCKS Power Door Lock System General Description The circuit consists of the door lock (& power window) Front Door Lock Actuator Removal 1. Refer to the Front Door Lock Assembly removal procedure in this section. 2. Remove the door lock actuator(1). 632RS021 632RS020 Front Door Lock Actuator Installation To install, follow the removal steps in the reverse order. Rear Door Lock Actuator Removal 1. Refer to the Rear Door Lock Assembly removal procedure in this section. 2. Removal the door lock actuator(1). 632RS019 |
