Opel Frontera UBS. Service manual - part 2838
8D–552
WIRING SYSTEM
Parts Location (RHD)
Legend
(1) I-9(2) SRS Coil Assembly(3) U-5(4) U-1(5) H-7, H-65(6) C-16(7) C-63
(8) H-5(9) E-30
(10) U-2(11) Fuse Box(12) Relay and Fuse Box(13) H-61, H-62(14) Fuse Box (C-21)
D08RW622
14
1
2
3
4
5
6
7
8
9
10
11
12
13
