8B–8 WIPER/WASHER SYSTEM Rear Wiper Motor Removal 1. Disconnect the battery ground cable. Refer to the removal steps of the Rear Wiper 4. Disconnect the connector remove the wiper shaft nut, remove the fixing screws and then remove the rear 885RS013 Installation To install, follow the removal steps in the reverse order, 1. Before installing the wiper arm/blade to the motor shaft, confirm that the motor stops at the auto-stop 2. Install the wiper arm so that the blade gets parallel to the lowermost heat wire(2) of the rear defogger 885RS012 885RS011 3. Tighten the motor shaft nut to the specified torque. Torque: 6 N·m (0.6 kg·m/52 lb in) 4. Tighten the wiper arm nut to the specified torque. Torque: 9 N·m (0.9 kg·m/78 lb in) |
