MUA MODEL 7B1 – 51 REMOVAL AND INSTALLATION Read this Section carefully before performing any removal and installation procedure. This Section gives Important Operations – Removal Battery Cable Disconnect the negative (–) cable from the battery Engine Hood Apply setting marks to the engine hood and the engine Gear Shift Lever and Transfer Change Lever 1. Place the gear shift lever in the neutral position. 2. Place the transfer change lever in the “H” position. 3. Remove the gear shift lever knob and transfer change lever konb. 4. Remove the center console assembly and front console assembly. 5. Remove the grommet and dust cover. 6. Remove the gear shift lever cover bolt. 7. Remove the gear shift lever. 8. Remove the transfer change lever retainer bolts. 9. Remove the transfer change lever and O-ring. Note: Cover the shift lever and change lever holes to prevent Lifting the Vehicle 1. Jack up the vehicle. 2. Place chassis stands at the front and the rear of the vehicle. Transfer Case Protector (Except 00 Year or Subsequent Remove the transfer case protector from the transmission 235RT004 |
