AUTOMATIC TRANSMISSION (AW30-40LE) 7A–167 247RY00035 247RY00036 247RY00037 247RY00038 Important operations 1. Ring gear flange Install ring gear flange to the ring gear. 2. Snap ring Install snap ring to the ring gear. 3. Thrust bearing and race Coat the races and bearing with petroleum jelly, and install 4. Thrust washer (Plastic) 5. Thrust washer (Plastic) Coat the thrust washer with petroleum jelly. NOTE: 6. One–way clutch Install the one–way clutch with the flanged side facing Races and bearing diameter (Reference) mm (in.) Inside Outside Race (A) 28.8 (1.134) 44.8 (1.764) Bearing 30.1 (1.185) 44.7 (1.760) Race (B) 27.8 (1.095) 44.8 (1.764) |
