AUTOMATIC TRANSMISSION (AW30-40LE) 7A–107 DISASSEMBLY, INSPECTION AND The instructions here are organized so that you work on only GENERAL CLEANING NOTES: 1. All disassembled parts should be washed clean and any fluid passages and holes blown through with compressed 2. When using compressed air to dry parts, always aim away from yourself to prevent accidentally spraying automatic 3. The recommended automatic transmission fluid should be used for cleaning. PARTS ARRANGEMENT: 1. After cleaning, the parts should be arranged in proper order to allow performing inspection, repairs, and reassembly 2. When disassembling a valve body, be sure to keep each valve together with the corresponding spring. 3. New brakes and clutches that are to be used for replacement must be soaked in transmission fluid for at GENERAL ASSEMBLY: 1. All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be coated with transmission 2. All gaskets and rubber O-rings should be replaced. 3. Make sure that ends of a snap ring are not aligned with one of the cutouts and are installed in the groove correctly. 4. If a worn bushing is to be replaced, the subassembly containing that bushing must be replaced. 5. Check thrust bearings and races for wear or damage. Replace if necessary. 6. Use petroleum jelly or vaseline to keep parts in place. |
