AUTOMATIC TRANSMISSION (AW30-40LE) 7A–79 244RY00005 101RY00004 249RW003 242RW013 Look-up solenoid (Normal open type) THROTTLE POSITION SENSOR 1. Turn the starter switch to the "ON" position. 2. Measure the voltage between throttle position sensor connector terminals 2 (output) and 3 (ground). NOTE: • Do not remove the sensor connector. • Make sure that power source (4.75-5.25V) is measured between terminals 1 and 3 before measurement at step ATF TEMPERATURE SENSOR 1. Disconnect the front side ATF cooler pipe from the elbow and remove the elbow. 2. Remove the ATF temperature sensor from the transmission case. 3. Place the ATF temperature sensor in a container of ATF. 4. Measure the resistance between each terminals. 5. If either of the measured values exceeds the specified, replace the ATF temperature sensor. N · m (kg · m/ lb · ft) When battery terminal is disconnected Air passes through When battery terminal is connected No air leaks Throttle position Voltage (V) Idle 0.25-0.45 WOT 3.74-4.56 Resistance 0.5 - 30 k Ω (0 ° C - 120 ° C) Torque 15 (1.5/11) |
