Opel Frontera UBS. Service manual - part 2386





6A – 18 ENGINE MECHANICAL

Engine Electricals

N·m (kg·m/lb·ft)

060R200291

A

A

15(1.5/11)

85(8.7/63)

40(4.1/30)

40(4.1/30)

24(2.4/17)

20(2.0/14)

ENGINE MECHANICAL 6A – 19

Injector

N·m (kg·m/lb·ft)

E06R200027

With
spacer type

Without
spacer type

20N·m(2.0kg·m/14 Ib ft)

7N·m(0.7kg·m/61 Ib in)

Recheck tightening torque
after tighten the oil rail

Apply engine oil on the
thread of stud bolts

20N·m(2.0kg·m/14 Ib ft)

Tighten 30N·m(3.1kg·m/22 Ib ft)
Then loosen it again tighten with
25N·m(2.5kg·m/18 Ib ft)

Apply engine oil
both side

6A – 20 ENGINE MECHANICAL

High Pressure Oil Pipe

N·m (kg·m/lb·ft)

78(8.0/58)

78(8.0/58)

78(8.0/58)

78(8.0/58)

052R200003

ENGINE MECHANICAL 6A – 21

Air Duct and Intercooler (For General Export)

N·m (kg·m/lb·ft)

3(0.3/26lb•in)

4(0.4/35lb•in)

20(2.0/14)

4(0.4/35lb•in)

20(2.0/14)

135R200004
