6E–512 6VE1 3.5 ENGINE DRIVEABILITY AND EMISSIONS 2. Connect the fuel vapor connector to the EVAP canister vent solenoid. 3. Connect the three hoses to the EVAP canister. 014RW145 4. Disconnect the negative battery cable. EVAP Canister Purge Solenoid (Purge Duty Solenoid Valve) Removal Procedure 1. Disconnect the negative battery cable. canister purge solenoid. 3. Disconnect the vacuum hoses from the EVAP canister purge solenoid. 060R200229 4. Remove the EVAP canister purge solenoid retaining bolt from the common chamber. 5. Remove the EVAP canister purge solenoid. Installation Procedure 1. Install the EVAP canister purge solenoid on the upper intake manifold. 2. Install the EVAP canister purge solenoid retaining bolt. Tighten D Tighten the bolts to 20 N·m (16 lb ft.). 3. Connect the vacuum hoses to the EVAP canister purge solenoid. 4. Connect the electrical connector to the EVAP canister purge solenoid. 060R200229 Fuel Tank Vent Valve Removal and Installation Procedure Refer to Fuel Pump section. |
