6E–492 6VE1 3.5 ENGINE DRIVEABILITY AND EMISSIONS 2. Connect the ION sensing module connectors as shown in the illustration. 060RY00003 Legend (1) Green Color Connector 3. Connect the negative battery cable. Mass Air Flow (MAF) Sensor Removal Procedure 1. Disconnect the negative battery cable. sensor. TS23740 3. Loosen the clamps which secure the intake air duct and the air cleaner to the MAF sensor. 4. Remove the intake air duct from the MAF sensor. TS23781 Installation Procedure 1. Install the MAF sensor on the air cleaner with the clamp. 2. Install the intake air duct and the clamp on the MAF sensor. TS23781 3. Tighten the clamps to secure the MAF sensor to the intake air duct and the air cleaner. 4. Connect the MAF electrical connector. |
