5D – 2 PARKING BRAKES MAIN DATA AND SPECIFICATIONS REAR PARKING BRAKE Type Duo-servo Lining Dimensions cm 2 (in 2 ) 121.2 (18.79) Adjusting Method Manual Adjusting Rear Drum (in Disc) mm (in) 210 (8.27) Parking Brake Lever Stroke 6 to 7 notches When pulled with a force of 30 kg (66 lb) SERVICE STANDARD REAR PARKING BRAKE Rear Drum (in Disc) Minimum Wear Inside Diameter mm (in) 211.4 (8.32) Parking Brake Lining Thickness Minimum Limit mm (in) 1.0 (0.039) Parking Brake Lever Stroke 6 to 7 notches When pulled with a force of 30 kg (66 lb) |
