6G–7 ENGINE LUBRICATION Oil Pan and Crankcase Removal 1. Disconnect battery ground cable. each per side and remove suspension cross member. 9. Remove pitman arm and relay lever assembly, using the 5–8840–2005–0 remover, remove pitman arm 10. Remove axle housing assembly four fixing bolts from housing isolator side and mounting bolts from wheel 11. Remove oil pan fixing bolts. 12. Remove oil pan, using 5–8840–2153–0 sealer cutter, remove oil pan. 013RS003 13. Remove crankcase fixing bolts. cutter, remove crankcase. NOTE: Do not deform or damage the flange of oil pan and 013RS003 Installation 1. Install crankcase. 1. Remove residual sealant, lubricant and moisture from mounting surface, then dry thoroughly. 2. Properly apply a 4.5 mm (0.7 in) wide bead of sealant (TB-1207C or equivalent) to mounting D The crankcase must be installed within 5 013RW010 |
