6A–90 ENGINE MECHANICAL Main Data and Specification General Specification Item Specifications Item 6VD1 6VE1 Engine type, number of cylinders and arrangement Water cooled, four cycle V6 Form of combustion chamber Pent roof type Valve mechanism 4-Cams, 4-Valves, DOHC Gear & Belt Drive Cylinder liner type Casted in cylinder drive Total piston displacement 3165 cc 3494 cc Cylinder bore x stroke 93.4mm x 77.0mm 93.4mm x 85.0mm (3.6772 in x 3.0315 in) (3.6772 in x 3.3465 in) Compression ratio 9.1 : 1 Compression pressure at 300rpm 14.0 Kg/cm @ Engine idling speed rpm Non adjustable (750) Valve clearance Intake: 0.28 mm (0.11 in) Exhaust: 0.30mm (0.12in) Oil capacity 5.3 liters Ignition timing Non adjustable Non adjustable 16 ° BTDC at idle rpm) (20 ° BTDC at idle rpm) Spark plug K16PR–P11, PK16PR11, RC10PYP4 Plug gap 1.0 mm–1.1 mm(0.0394 in – 0.0433 in) |
