4B2–111 DRIVE LINE CONTROL SYSTEM (TOD) D04RY00072 Step Action Yes No 1 Disconnect the ECU connector from ECU. Is the continuity established between terminals (B–68)8 and Go to Step 2 The ECU has failed. Replace the ECU. Go to Step 3 2 Is the self-diagnostic connector short-circuited? Go to Step 3 Repair the self-diagnostic connector circuit. Go to Step 3 3 1. Check that all the parts are mounted. Is this step complete? Repeat the “Diagnosis Flow”. Return to Step 3 |
