4D2–36 TRANSFER CASE (TOD) 10. Install the reduction fork assembly together with reduction hub to the transfer case assembly. 11. Install the shifter shaft assembly. 261RW019 12. Tighten the cam pilot block set bolts to the specified torque. Torque : 12 N·m (1.2 kg·m/104 lb in) 13. Tighten the detent spring to the specified torque. Torque : 24 N·m (2.4 kg·m/17 lb in) 261RW022 14. Apply ATF to the needle bearing inside the input shaft assembly. 15. Install the output shaft to the transfer case. |
