SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL & COLUMN 2A – 65 CAUTION: 1. Front Console Assembly 1) Remove the transmission (for M/T) and transfer control lever knob. 2) Disconnect the wiring harness connectors. 2. Lower Cluster Assembly 3. Steering Lower Cover Remove the engine hood opening lever. 4. Inflator Module 1) Loosen the inflator module fixing bolt from behind the steering wheel assembly using a driver or equivalent until the inflator module can be released from steering assembly. 2) Disconnect the yellow 2way SRS connector located behind the inflator module. WARNING 827RS014 827RS015 827RS016 Up |
