8I–8 SUN ROOF/CONVERTIBLE TOP 7. Remove the cable outer tube(2) fixing screws. guide rail fixing nuts(5). 9. Prying the guide rail a little with a screwdriver, draw the outer tube out of the grommet(3). D At this time, the inner cable(4) remains on the frame 10. Remove the sun roof frame assembly. 665RS012 Reassembly To reassembly, follow the disassembly steps in the 1. When installing the motor or drive unit, set the sun roof set plate in the full closed position by pushing the 2. When installing the sun roof glass(1) to the sun roof set plate, insert the original shims in the same position 665RS013 |
