SECURITY AND LOCKS 8H–13 4. Disconnect the locking links (arrow marks positions), remove three fixing screws and then remove the 683RW015 Legend (1) To Inside Lock Knob Installation To install, follow the removal steps in the reverse order, 1. Apply chassis grease to the lock assembly and striker moving surface. 2. Tighten the tailgate lock assembly fixing screws to the specified torque. Torque: 7 N·m (0.7kg·m/61 lb in) 3. Check that the tailgate lock operates correctly after installing it. |
