8F–87 BODY STRUCTURE Spare Tire Carrier Parts Location 530RS001 Legend (1) Spare Tire Removal 1. Remove spare tire. D Remove the special bolts by using special tool (If so D Spare tire carrier bolt wrench 5–8840–2095–0 530RS002 Installation 1. Install the spare tire carrier. D Tighten the carrier fixing bolts to the specified Torque : 31 N • m (3.2kg·m/23 lb ft) 2. Install the spare tire. D Tighten the spare tire fixing bolts to the specified Torque : 118 N • m (12.0kg·m/87 lb ft) |
