Opel Frontera UBS. Service manual - part 1664
8D–334
WIRING SYSTEM
Parts Location (RHD)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
D08RW938
Legend
(1) I-4(2) C-16(3) H-7, H-9, H-24(4) B-6, B-7(5) B-2(6) C-23(7) Headlight Wiper Motor-LH(8) Headlight Wiper Motor-RH
(9) C-30
(10) H-41(11) C-36(12) Washer Tank(13) Relay and Fuse Box(14) B-18, B-19(15) H-15, H-26(16) Fuse Box(17) B-26
